PARKER 787ST-16 Hydraulic Hose, High Super Tough Cover, Constant Pressure 5000 Psi
Get it by Tuesday, Aug 25
€92.51 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Hydraulic Hose |
| Application Type | Petroleum Base Hydraulic Fluids, Lubricating Oils |
| Color | Black |
| Design | Supertough Cover (Abrasion-Resistant 450x)Half ISO Bendreinforced With 4 Or 6 Compact Spiral Steel Wiressold In Unit Of Length (Bulk)For Hydraulics/Lubrication |
| Equivalent To | 787ST16 |
| Function | High-Pressure Hydraulic Tubing / Tube / Hose |
| Inside Dia. | 1" |
| Label Color | Red |
| Main Function | Hose |
| Material | Proprietary Synthetic Rubber Inner Tube Synthetic Rubber Super Abrasion-Resistant Cover |
| Max. Operating Pressure | 5000 psi |
| Media Temp. | -40°F to +257°F |
| Min. Bending Radius | 6" |
| Min. Burst Pressure | 20000 psi |
| Outside Dia. | 1 2/5" |
| Product Datasheet | parker-387-10.pdf |
| Sub Range Name | 787 Series (GlobalCore) |
Shipping Info:
| Ship weight (kg) | 0.53 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
Documentation:
