PARKER 24M-4-4 Air Brake Fitting, 1/4 Inch Outside Diameter, Composite
Item: BT6VTAModel: 24M-4-4Cross Ref: 48MA55
7 In Stock
Ships within 2 days via
10.00% off
€127.27 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Air Brake Fitting |
| Application | Heavy Duty Truck, Trailer, Mobile |
| Body Material | Composite |
| Color | Black |
| Compatible Tube Material | Nylon (J844 Type A And B), Stainless Steel |
| Configuration Sub-type | Manifold |
| Configuration Type | Tube to Tube |
| Connection Type | NPTF |
| Fitting Material | Composite |
| Fitting Side A Connection Type | Push-To-Connect |
| Fitting Side A Tube Outer Dia. | 1/4" |
| Fitting Side B Connection Type | Push-To-Connect |
| Fitting Side B Tube Outer Diameter | 1/4" |
| Gasket Material | Buna N |
| Includes Pre-applied Thread Sealant | No |
| Length | 3.98" |
| Material | Composite, Brass |
| Max. Operating Pressure | 250 psi |
| Max. Operating Temp. | 93 Deg C |
| Max. Operating Temp. | 93°C |
| Maximum Operating Temperature | 200°F |
| Min. Operating Temp. | -40°C |
| Minimum Operating Temperature | -40°F |
| Operating Temp. Range | -40°F to +200°F |
| Outer Diameter 1 | 1/4" |
| Overall Length | 3 31/32" |
| Pressure Range | 0 psi to 250 psi |
| Product Datasheet | parker-24m-4-4.pdf |
| Release Type | Button |
| Resistance Properties | Compact Resistant, Impact Resistant |
| Ring Material | Buna N |
| Series | PTC COMPOSITE Series |
| Shape | Manifold |
| Specific Application | Air Brakes, Air Tanks, Air Ride, Sliders, Tire Inflation, Primary And Secondary, Air Lines, Cab Controls |
| Specific Fitting Shape | 4 Outlet Manifold |
| Style | Push To Connect |
| System Of Measurement | Inch |
| Tube Outside Dia. | 1/4" |
Shipping Info:
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 0.64 |
| Ship length (cm) | 10.11 |
| Ship width (cm) | 2.54 |
| Country of Origin | MX |
Documentation:
Product Variants
| Model | Max. Operating Temp. | Min. Operating Temp. | Fitting Side A Connection Type | Fitting Side B Connection Type | Fitting Side B Tube Outer Diameter | Overall Length | Fitting Side A Tube Outer Diameter | Fitting Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 24M-8-8 | 200°F | 40°F | Push To Connect | Push To Connect | 1/2" | 6 1/2" | 1/2" | Composite | €268.30 | |
| 24M-6-4 | 200°F | 40°F | Push To Connect | Push To Connect | 1/4" | 4" | 3/8" | Composite | €127.84 | |
| 24M-6-6 | 200°F | 40°F | Push To Connect | Push To Connect | 3/8" | 6 1/2" | 3/8" | Composite | €245.06 |
