PARKER 12F32EC Coalescing filter, 0.01 micron, 1/2 Inch NPT, 160 scfm, 250 psig Max Op Pressure
Item: BT6YVTModel: 12F32ECCross Ref: 801TD5
7 In Stock
Ships within 2 days via
10.00% off
€466.66 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Air Preparation Product Type | Coalescing Filter |
| Air Preparation Series | General Industrial Series |
| Body Material | Zinc |
| Bowl Type | Poly With Bowl Guard |
| Connection Style | Air Line |
| Differential Pressure Indicator Included | Yes |
| Drain Included | Yes |
| Drain Type | Automatic |
| Element Rating | 0.01 µm |
| Filter Bowl Capacity | 7.2 oz. |
| Filter Bowl Guard Included | Yes |
| Filter Bowl Guard Material | Metal |
| Filter Bowl Material | Polycarbonate |
| Filter Drain Type | Manual |
| Flow Range | 25-75 SCFM |
| For Fluid Type | Gas, Oil |
| Gauge Included | No |
| Inlet Size | 1/2 |
| Inlet Type | NPT |
| Maximum Flow Rate | 160 SCFM |
| Maximum Operating Pressure | 250 psig |
| Maximum Operating Temperature | 175°F |
| Minimum Flow Rate | 75 SCFM |
| Minimum Operating Temperature | 32°F |
| Operating Temp. Range | 0°C to 52°C |
| Overall Depth | 3 1/4" |
| Overall Height | 8 5/8" |
| Overall Width | 3 1/4" |
| Port Inch/bsp | NPT |
| Port Size | 1/2" |
| Port Type | NPT |
| Pressure Drop | 2 psig |
| Seal Material | Nitrile |
| Series | 12F STANDARD Series |
| Supply Pressure Range | 0 psig to 150 psig |
| Weight | 2.4 lbs. |
Shipping Info:
| Ship weight (kg) | 1.17 |
| Ship height (cm) | 21.91 |
| Ship length (cm) | 8.26 |
| Ship width (cm) | 8.26 |
| Country of Origin | US |
