OSG 7810000 Parallelogram Milling Insert, 16 mm Inscribed Circle, 10 mm Corner Radius, 6.35 mm Thick | CT6BZE 53HM69

OSG 7810000 Parallelogram Milling Insert, 16 mm Inscribed Circle, 10 mm Corner Radius, 6.35 mm Thick

Item: CT6BZEModel: 7810000Cross Ref: 53HM69
7 In Stock

Ships within 2 days via

€45.14
10.00% off
€40.63 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Milling Insert
Ansi Code ADMT2006100PDR-GM
Cast Iron (k) Compatibility Yes
Chip-breaker Yes
Chip-breaker Code GM
Coating PVD
Coating Process PVD
Compatibility Yes
Corner Radius 10 mm
Cutting Direction Right Hand
Features Can Accommodate A Wide Range Of Workpiece Materials
Finish - Machining TiAlN
For Toolholder PDR20R063M22-3, PDR20R063M22-4, PDR20R063M25.4-3, PDR20R063M25.4-4, PDR20R080M27-4, PDR20R080M27-5, PDR20R080M31.7-4, PDR20R080M31.7-5, PDR20R100M31.7-5, PDR20R100M31.7-6, PDR20R100M32-5, PDR20R100M32-6, PDR20R125M31.7-6
For Use With Indexable Ballnose End Mills
Hardened Compatibility No
Hole Type 40° To 60° Countersink Hole
Inscribed Circle 16 mm
Insert Application Finishing
Insert Size 2006100
Insert Style ADMT
Iso Number ADMT2006100PDR-GM
Manufacturer Grade Grade XP3930
Material Carbide
Material - Machining Carbide
Mounting Style Screw
No. Of Edges 2
Non Ferrous (n) Compatibility No
Primary Material Application Cast Iron, Steel
Primary Material Application Iso Code K, P
Series 78PDR Series
Shape Parallelogram
Stainless Compatibility No
Super Alloy Compatibility No
System Of Measurement Metric
Thickness 6.35 mm
Width 16 mm
Workpiece Compatibility Steel

Shipping Info:

Ship weight (kg) 0.02
Ship height (cm)2.54
Ship length (cm)2.54
Ship width (cm)2.54

Product Variants

ProductModelCorner RadiusInscribed CircleThicknessIso NumberAnsi NumberInsert SizeShapeNo. Of EdgesPrice
OSG 52201050 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0150 Inch Corner Radius | CT6BLW 53HR25 522010500.015"3/8"2.6 mmPFR0375R015-SH-375Parallelogram1€127.72
OSG 52201000 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0150 Inch Corner Radius | CT6BLX 53HP95 522010000.015"3/8"2.6 mmPFR0375R015-STPFR0375R015-ST375Parallelogram1€127.72
OSG 52201100 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0150 Inch Corner Radius | CT6BLY 53HR54 522011000.015"3/8"2.6 mmPFR0375R015A-DPFR0375R015A-D375Parallelogram1€291.45
OSG 52201101 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0300 Inch Corner Radius | CT6BLZ 53HR55 522011010.03"3/8"2.6 mmPFR0375R030A-DPFR0375R030A-D375Parallelogram1€291.45
OSG 52201001 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0300 Inch Corner Radius | CT6BMA 53HP96 522010010.03"3/8"2.6 mmPFR0375R030-STPFR0375R030-ST375Parallelogram1€127.72
OSG 52201102 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0600 Inch Corner Radius | CT6BMB 53HR56 522011020.06"3/8"2.6 mmPFR0375R060A-DPFR0375R060A-D375Parallelogram1€291.45
OSG 52201002 Parallelogram Milling Insert, 0.375 Inch Inscribed Circle, 0.0600 Inch Corner Radius | CT6BMC 53HP97 522010020.06"3/8"2.6 mmPFR0375R060-STPFR0375R060-ST375Parallelogram1€127.72
