OMRON S8VK-X12024-EIP Power Supply, 100 To 240 V AC, Single, 24 V DC, 120 W, 5 A, Din Rail | CT4MUW 803VK1

OMRON S8VK-X12024-EIP Power Supply, 100 To 240 V AC, Single, 24 V DC, 120 W, 5 A, Din Rail

Item: CT4MUWModel: S8VK-X12024-EIPCross Ref: 803VK1
7 In Stock

Ships within 2 days via

€689.25
10.00% off
€620.32 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Power Supply
Current - Inrush 32A
Current - Output 5A
Current - Peak 6A
Depth 92.3 mm
Features Power Boost Function At 150% (240 And 480 W), Product Replacement Time, Output Voltage, Output Current, And More Are Acquired On The Network And Can Be Managed All At Once, Product Status Can Be Checked On-Site Using The Indication Monitor, Side-By-Side Mounting Possible (Upto 55°C), Ul Class 2 Conformance (90 W Or Less)
Frequency 50/60 Hz
Height 94.7 mm
Hold Up Time 35 ms @ 115V AC, 35 ms @ 230V AC
Hold Up Time - Minimum 35 ms
Input Frequency - Maximuim 63 Hz
Input Frequency - Minimum 47 Hz
Input Frequency - Nominal 50/60 Hz
Input Voltage 100-240V AC
Ip Rating IP20
Manufacturer Warranty 5 yrs.
Maximum Efficiency @ 115v Ac 90%
Maximum Efficiency @ 230v Ac 92%
Mean Time Between Failures (mtbf) 140000 hrs.
Mounting Din Rail
Operating Temp. Range -40°C to +70°C
Operating Temperature - Maximum 158°F
Operating Temperature - Minimum -40°F
Output Noise - Maximum 150 mV
Output Power - Rated 120 W
Output Voltage 24V DC
Output Voltage - Nominal 24V DC
Overall Depth 3.63"
Overall Height 3.73"
Overall Width 2.17"
Peak Amps 6A
Phase Single
Power Rating 120 W
Power Supply Style Switching
Series S8VK-X Series
Special Features Alarm Indication, Led Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Series Operation
Start Up Time - Maximum 1000 ms
Status Indicator Green (Output), Red (Alarm)
Style Switching
Width 55 mm
Wire Connection Type Push In
Wire Size - Maximum 14 AWG
Wire Size - Minimum 18 AWG

Shipping Info:

Ship weight (kg) 0.45
Ship height (cm)9.47
Ship length (cm)9.23
Ship width (cm)5.5
Country of OriginCN
