OMRON 44534-0030 Safety Interlock Switch 2no 2nc 5a@100v
Item: AA2KBPModel: 44534-0030Cross Ref: 10N125
7 In Stock
Ships within 2 days via
5.00% off
€684.92 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Safety Interlock Switch |
| Ac Contact Rating | 4A @ 230V |
| Actuating Key Type | Flat |
| Actuator Length | 3.46" |
| Actuator Material | Stainless Steel |
| Body Material | Thermoplastic |
| Circuitry Action | Snap Action |
| Contact Form | 2NO, 2NC |
| Dc Contact Rating | 2A @ 24V |
| Differential Travel | 0.14" |
| Display Qty | 1 |
| Features | Locking Force Of 270 Lbs. (1200 N) |
| Hazardous Location Specification | Not Rated |
| Height | 7 14/25" |
| Included Actuating Key | Actuating Key Included |
| Ip Rating | IP67 |
| Key Hole Location | Front |
| Max. Operating Temp. | 131°F |
| Min. Operating Temp. | -4°F |
| Nema Enclosure Rating | NEMA 6 |
| Operating Force | 1.35 lbs. |
| Operating Temp. | -4°F to +131°F |
| Over Travel | 35 mm |
| Overall Depth | 1.57" |
| Overall Height | 7.56" |
| Overall Width | 1.57" |
| Positive Travel | 0.14" |
| Series | TL4019 Series |
| Solenoid Voltage | 24V AC/DC |
| Style | Actuating Key |
| Terminal Connection Type | M20 |
| Width | 1.57" |
Shipping Info:
| Ship weight (kg) | 0.61 |
| Ship height (cm) | 11.94 |
| Ship length (cm) | 23.37 |
| Ship width (cm) | 15.75 |
| HS code | 8536509065 |
| Country of Origin | DE |
Product Details:
- Special Features: Rotatable Head, Withstand Water Washdown Cleaning
