NTN ZUCFBL205-16 Flange Bearing 3-Bolt Ball 1 Bore
Item: AJ2DTVModel: ZUCFBL205-16Cross Ref: 49C728
7 In Stock
Ships within 2 days via
13.00% off
€207.02 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | 3-Bolt Flange Bearing |
| Application | Agriculture, Automotive, Cosmetic/Pharmaceutical, Food Processing, Industrial Machinery, Machine Tools, Material Handling, Refinery/Petrochemical |
| Bearing Insert Material | Alloy, Steel |
| Bearing Insert Type | Radial Ball |
| Bearing Material Grade | Grade 52100 |
| Bolt Center To Center Length | 1 5/8" |
| Bore Dia. | 1" |
| Bore Type | Cylindrical |
| Closure | Double Sealed |
| Closure Type | Double Sealed |
| Dynamic Load Capacity | 2680 lbf. |
| Expansion Type | Fixed |
| Finish | None |
| Flange Thickness | 1 21/64" |
| Grade | Grade 52100 |
| Housing Material | Polymer |
| Housing Material Finish | Unfinished |
| Housing Material Grade | PBT - Thermoplastic |
| Housing Type | Flange Bracket |
| Included | (3) Set Screws |
| Included Bearing | ZUCFBL205-16 |
| Included Bearing Cap | None |
| Insert Finish | Chrome Plated |
| Insert Material | Alloy Steel |
| Insert Type | Ball |
| Insert Type | Radial Ball |
| Lock Type | Set Screw |
| Lubricant Material | FDA, USDA-H1 Solid Grease |
| Lubrication | Caltex FM EP Or Equivalent USDA-H1 Grease |
| Lubrication Openings | One Zirc Fitting |
| Max. Speed | 5100 RPM |
| Max. Temp. | 250°F |
| Min. Temp. | -2°F |
| Mount Hole Center To Center Height | 1 1/8" |
| Mount Hole Center To Center Length | 1 5/8" |
| Mounting Bolt Size | 7/16" |
| Mounting Hole Center To Center | 1 5/8" |
| No. Of Mount Holes | 3 |
| Overall Height | 3 3/8" |
| Overall Length | 2 1/2" |
| Overall Width | 1 5/8" |
| Resistance Properties | Corrosion Resistant |
| Rolling Element Rows | 1 |
| Seal Material | Nitrile Rubber |
| Seal Type | Contact |
| Shaft Locking Type | Set Screw |
| Static Load Capacity | 1420 lbs. |
| Static Radial Load Capacity | 1420 lbf. |
| System Of Measurement | Imperial |
| Temp. | -4°F to +230°F |
Shipping Info:
| Ship weight (kg) | 0.32 |
| Ship height (cm) | 8.57 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 4.13 |
| Country of Origin | IL |
