NTN M12649 Tapered Roller Bearing Cones, 21.442 mm Bore, 34.5 mm OD
Item: CT4GAYModel: M12649Cross Ref: 798AL1
7 In Stock
Ships within 2 days via
10.00% off
€32.65 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Roller |
| Bearing Industry Number | M12649 |
| Bore Dia. | 21.442 mm |
| Bore Diameter | 27/32" |
| Bore Type | Tapered |
| Cage Material | Steel |
| Compatible Cup Manufacturer Part Number | M12610 |
| Cone Width | 18/25" |
| Dynamic Radial Load Capacity | 8550 lbf. |
| For Use With Mfr. Model Number | M12610 |
| Inside Dia. | 0.843" |
| Max. Temp. | 250°F |
| Min. Temp. | -40°F |
| Number Of Rows | 1 |
| Outside Dia. | 34.5 mm |
| Outside Diameter | 1.358" |
| Ring Material | Carbon Steel |
| Roller Material | Carbon Steel |
| Static Radial Load Capacity | 8750 lbf. |
Shipping Info:
| Ship weight (kg) | 0.12 |
| Ship height (cm) | 3.45 |
| Ship length (cm) | 3.45 |
| Ship width (cm) | 1.83 |
| Country of Origin | US |
Product Variants
| Model | Ring Material | Outside Dia. | Bore Dia. | Max. Temp. | Min. Temp. | Static Radial Load Capacity | Ring Material Grade | Bore Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 30304A | Steel | 52 mm | 20 mm | 120°C | -40°C | 34 kN | - | Cylindrical | €64.58 | |
| 32004X | Steel | 42 mm | 20 mm | 120°C | -40°C | 27.9 kN | - | Cylindrical | €64.11 | |
| 32005X | Steel | 47 mm | 25 mm | 120°C | -40°C | 33.5 kN | - | Cylindrical | €64.91 | |
| 32013X | Carbon Steel | 100 mm | 65 mm | 120°C | -40°C | 128 kN | Grade 52100 | Cylindrical | €194.92 | |
| 32024X | Steel | 180 mm | 120 mm | 120°C | -40°C | - | - | Cylindrical | €629.85 | |
| 33206 | Steel | 62 mm | 30 mm | 120°C | -40°C | 77 kN | - | Cylindrical | €92.46 | |
| LM67048/LM67010 | Steel | 2.312" | 1 1/4" | 248°F | -40°F | 9200 lbf. | - | Cylindrical | €47.39 |
