MITEE-BITE PRODUCTS INC 82584 Knife Edge Clmps Cam Action M10 20mm
Item: AH4CGRModel: 82584Cross Ref: 34CU65
7 In Stock
Ships within 2 days via
10.00% off
€245.24 /pkg. of 8
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Knife Edge Clamps |
| Bolt Thread Length | 19 mm |
| Bolt Thread Size | M10 |
| Clamp Body Material | Steel |
| Clamp Face Material | Steel |
| Clamp Face Type | Knife |
| Clamp Travel From Centerline | 1.27 mm |
| Clamp Type | Fixture Clamp |
| Clamping Length From Workpiece | 10.15 mm |
| Diameter | 10 mm |
| Drive Size | 7 mm |
| Force | 8900N |
| Head Height | 6.35 mm |
| Head Width | 20.6 mm |
| Material | Steel |
| Max Clamping Force | 8900N |
| Measurement System | Metric |
| Number Of Clamps | 8 |
| Overall Height | 25.35 mm |
| Overall Width | 20.6 mm |
| Thread Length | 20 mm |
Shipping Info:
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 12.7 |
| Ship width (cm) | 20.32 |
| Country of Origin | US |
Product Details:
- Clamp Style : Cam Action
Product Variants
| Model | Overall Width | Overall Height | Force | Diameter | Thread Length | Drive Size | Material | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 22584 | 0.812" | 0.96" | 2000 lbs. | - | 3/4" | 3/16" | Steel | 8 | €289.07 | |
| 22588B | 1" | 1.275" | 4000 lbs. | 1/2" | 1" | 5/16" | Steel | 8 | €308.23 | |
| 22592 | 1.187" | 1 5/8" | 6000 lbs. | 5/8" | 1 1/8" | 3/8" | Steel | 4 | €207.77 | |
| 82588 | 25.4 mm | 32.32 mm | - | 12 mm | - | 8 mm | Steel | 8 | €317.76 | |
| 82592 | 30.15 mm | 41.2 mm | 26700N | 16 mm | 30 mm | - | Steel | 4 | €212.38 |
