MERSEN FERRAZ U71007 Fuse Base, 750V, 100A, Semiconductor, 2 Pole, Tin Plated, Aluminium Box
Get it by Tuesday, Dec 23
€94.37 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Fuse Base |
| Ac Voltage Rating | 750V AC |
| Ac/dc | AC/DC |
| Amps | 100A |
| Body Material | Thermoplastic |
| Body/insulating Material | Thermoplastic |
| Frequency | 50/60 Hz |
| Fuse Installation Method | Clip In |
| Fuse Type | Semiconductor |
| Height | 55.9 mm |
| Installation Mounting | Screw Mount, Din Rail |
| Length | 99.1 mm |
| Max. Fuse Rating | 100A |
| Number Of Poles | 2 |
| Product Datasheet | mersen-ferraz-70305.pdf |
| Product Group | Fuse Bases |
| Rated Torque | 35 lbs.in. |
| Rated Voltage Ac Ul | 750V |
| Rated Voltage Dc Ul | 750V |
| Rohs Compliant | Yes |
| Short Circuit Current Rating (sccr) | 200 kA |
| Torque Rating | 3.954 N-m |
| Width | 62.2 mm |
| Wire Material | Aluminum, Copper |
| Wiring Range | #2 to 14 |
Shipping Info:
| Ship weight (kg) | 1.25 |
| Ship height (cm) | 19.69 |
| Ship length (cm) | 15.57 |
| Ship width (cm) | 15.54 |
Documentation:
Product Variants
| Model | Amps | Max. Fuse Rating | Height | Number Of Poles | Rated Torque | Body Material | Ac Voltage Rating | Fuse Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 70305 | 30A | 30A | 34.8 mm | Adder | - | Thermoplastic | 750V AC | - | €24.39 | |
| 70306 | 30A | 30A | 34.8 mm | 1 | - | Thermoplastic | 750V AC | - | €33.57 | |
| 70307 | 30A | 30A | 34.8 mm | 2 | 35 lbs.in. | Thermoplastic | 750V AC | Semiconductor | €58.45 | |
| 70308 | 30A | 30A | 34.8 mm | 3 | 35 lbs.in. | Thermoplastic | 750V AC | Semiconductor | €84.87 | |
| 70315 | 30A | 30A | 34.8 mm | Adder | 20 lbs.in. | Thermoplastic | 750V AC | Semiconductor | €13.50 | |
| 70316 | 30A | 30A | 34.8 mm | 1 | 20 lbs.in. | Thermoplastic | 750V AC | Semiconductor | €22.03 | |
| 70317 | 30A | 30A | 34.8 mm | 2 | 20 lbs.in. | Thermoplastic | 750V AC | Semiconductor | €38.76 |
