MERSEN FERRAZ STXR600D05A Surge Protection Device, Type 1, 600V, 50kA
Get it by Friday, Aug 21
€450.24 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Surge Protection Device |
| Ac/dc | AC |
| Body Material | Polycarbonate |
| Enclosure Material | Non Metallic |
| Enclosure Nema Type | NEMA 4X |
| Format | STXR |
| Frequency | 50/60 Hz |
| Height | 85.1 mm |
| Indication System | Yes |
| Indication System Type | Led And Remote Audible Alarm |
| Installation Mounting | Panel Mount |
| Length | 82.6 mm |
| Mcov L-g | 690V |
| Mcov L-l | 840V |
| Nominal Discharge Amps | 20 kA |
| Product Datasheet | mersen-ferraz-stxr120p05.pdf |
| Product Group | Power Line SPDS |
| Rohs Compliant | Yes |
| System Configuration | 3 Phase Delta |
| Ul Spd Type | Type 1 |
| Vpr L-g | 2500V |
| Vpr L-l | 2500V |
| Width | 85.1 mm |
Shipping Info:
| Ship weight (kg) | 0.72 |
| Ship height (cm) | 8.51 |
| Ship length (cm) | 8.26 |
| Ship width (cm) | 8.51 |
Product Details:
- LED Indicator And Remote
Documentation:
Product Variants
| Model | Height | Nominal Discharge Amps | Installation Mounting | Indication System Type | System Configuration | Mcov L-g | Vpr L-g | Mcov L-l | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| STXR120P05 | 85.1 mm | 20 kA | Panel Mount | LED | Single Phase | 300V | 1000V | - | €271.80 | |
| STXR120P05A | 85.1 mm | 20 kA | Panel Mount | Led And Remote Audible Alarm | Single Phase | 300V | 1000V | - | €384.70 | |
| STXR120P05AN | 85.1 mm | 20 kA | Panel Mount | Led And Remote Audible Alarm | Single Phase | 300V | 1000V | - | €427.44 | |
| STXR120P05N | 85.1 mm | 20 kA | Panel Mount | LED | Single Phase | 300V | 1000V | - | €333.40 | |
| STXR208Y05 | 85.1 mm | 20 kA | Panel Mount | LED | 3 Phase Wye | 300V | 1000V | 300V | €356.20 | |
| STXR208Y05A | 85.1 mm | 20 kA | Panel Mount | Led And Remote Audible Alarm | 3 Phase Wye | 300V | 1000V | 300V | €450.24 | |
| STXR208Y05N | 85.1 mm | 20 kA | Panel Mount | LED | 3 Phase Wye | 300V | 1000V | 300V | - | RFQ
|
