MERSEN FERRAZ ST6003PY Surge Protection Device, 600/347V, 50kA, 3 Pole
Get it by Monday, Feb 16
€363.00 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Surge Protection Device |
| Ac/dc | AC |
| Body Material | Polyethelene Terphthalate |
| Connection/terminal Material | Steel |
| Connection/terminal Type | Box |
| Finish | Zinc Plated |
| Frequency | 50/60 Hz |
| Height | 68.6 mm |
| Indication System | Yes |
| Indication System Type | Visual Indicator |
| Installation Mounting | DIN Rail |
| Length | 90.9 mm |
| Mcov L-g | 690V |
| Mcov L-l | 840V |
| Mcov L-n | 420V |
| Mcov N-g | 270V |
| Nominal Discharge Current | 20 kA |
| Number Of Poles | 4 |
| Number Of Wires | 5 |
| Product Datasheet | mersen-ferraz-st1201pg.pdf |
| Product Group | Power Line SPDS |
| Rohs Compliant | Yes |
| System Configuration | 3 Phase Wye |
| Torque Rating | 1.695 N-m |
| Ul Spd Type | Type 1 Component Assembly |
| Vpr L-g | 2500V |
| Vpr L-l | 4000V |
| Vpr L-n | 4000V |
| Vpr N-g | 3000V |
| Width | 53.3 mm |
Shipping Info:
| Ship weight (kg) | 0.38 |
| Ship height (cm) | 6.86 |
| Ship length (cm) | 9.09 |
| Ship width (cm) | 5.33 |
Product Details:
- Visual Indicator, Star Connection
Documentation:
Product Variants
| Model | Number Of Poles | Number Of Wires | Height | Nominal Discharge Current | Ul Spd Type | Body Material | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|
| ST1201PG | 1 | 2 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €120.24 | |
| ST1201PGM | 1 | 2 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €137.40 | |
| ST2083PY | 4 | 5 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €327.36 | |
| ST2083PYG | 3 | 4 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €239.70 | |
| ST2083PYGM | 3 | 4 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €275.88 | |
| ST2083PYM | 4 | 5 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €376.20 | |
| ST2301PG | 1 | 2 | 68.6 mm | 20 kA | Type 1 Component Assembly | Polyethelene Terphthalate | 1 | €120.24 |
