MERSEN FERRAZ MPDB63153 Distribution Block, Standard, 600V, 175A, 1 Pole
Item: AF8EBPModel: MPDB63153Cross Ref: 25CC10
7 In Stock
Ships within 2 days via
5.00% off
€34.43 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Power Distribution Block |
| Ac Voltage Rating | 1000V |
| Ac/dc | AC/DC |
| Amps | 135A |
| Amps Al | 135A |
| Amps Cu | 175A |
| Body Material | GFPC |
| Body/insulating Material | Glass Filled Polycarbonate |
| Connector Material | Aluminum |
| Connector Material Finish | Tin Plated |
| Connector Type | Box |
| Contact Finish | TiN Plated |
| Contact Material | Aluminum |
| Depth | 2.81" |
| Flammability Rating | Ul94-V0 |
| For Conductor Material | Aluminum |
| For Max. Line Wire Size | 2/0 AWG |
| For Max. Load Wire Size | 2/0 AWG |
| For Min. Line Wire Size | 14 AWG |
| For Min. Load Wire Size | 14 AWG |
| Frequency | 50/60 Hz |
| Height | 71.4 mm |
| Housing Color | Black |
| Housing Material | Polycarbonate |
| Installation Mounting | Direct Screw Mount |
| Length | 3 2/25" , 73.9 mm |
| Line Connections/pole | 1 |
| Line Side Connection Type | Lug |
| Load Connections/pole | 1 |
| Load Side Connection Type | Lug |
| Max. Amps | 175A |
| Max. Voltage | 1000V AC/DC |
| Mounting Style | Panel |
| Mounting Type | Surface Mount |
| No. Of Poles | 3 |
| Overall Depth | 2.81" |
| Overall Length | 3.08" |
| Overall Width | 2.91" |
| Pitch | 23.6 mm |
| Power Distribution Block Design | Open |
| Primary Hex/screw Size | 7/16"-20 x 0.55 |
| Primary Hole Dia. | 11/25" |
| Primary No. Of Openings Per Pole | 1 |
| Primary Torque Rating | 2/0-#6 120, #8-#14 50 |
| Primary Wire Range | #14 AWG to 2/0 AWG |
| Primary Wire Range | 14 to 2/0 AWG |
| Product Datasheet | mersen-ferraz-mpdbc6263.pdf |
| Product Group | Power Distribution Blocks |
| Rated Voltage Ac Ul | 1000V |
| Rated Voltage Dc Ul | 1000V |
| Rohs Compliant | Yes |
| Secondary Connection/pole | 1 |
| Secondary Hex/screw Size | 7/16"-20 |
| Secondary Hex/screw Size Thread Length | 0.55" |
| Secondary Hole Dia. | 11/25" |
| Secondary No. Of Openings Per Pole | 1 |
| Secondary Torque Rating | 2/0-#6 120, #8-#14 50 |
| Secondary Wire Range | 2/0 AWG to #14 |
| Secondary Wire Range (awg) | 14 AWG to 2/0 AWG |
| Short Circuit Rating Class Cc | 100 Ka With 30A Fuse |
| Short Circuit Rating Class G | 100 Ka With 60A Fuse |
| Short Circuit Rating Class J | 100 kA With 200A Fuse |
| Short Circuit Rating Class L | 100 kA With 200A Fuse |
| Short Circuit Rating Class Rk1 | 100 kA With 100A Fuse |
| Short Circuit Rating Class Rk5 | 100 kA With 30A Fuse |
| Short Circuit Rating Class T | 100 kA With 200A Fuse |
| Short Circuit Rating Standalone | 10 kA |
| Standards | Csa Class 6228-01, Ul 1953 |
| Terminal Material | Aluminum |
| Type | Open-Style Power Distribution Block |
| Voltage | 1 kV , 600V AC/DC |
| Width | 2.91" , 78.1 mm |
Shipping Info:
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 7.32 |
| Ship length (cm) | 17.15 |
| Ship width (cm) | 7.95 |
| HS code | 8536904000 |
| Country of Origin | MX |
Product Details:
- Primary Connections/Pole (1)
- Power Distribution Block Design (Open)
Documentation:
Product Variants
| Product | Model | Voltage | For Conductor Material | Line Connections/pole | Load Connections/pole | Height | Connector Material | Primary Wire Range | Connector Type | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MPDBC6263 | - | - | - | - | 2 mm | - | - | - | 1 | €6.47 | |
 |
MPDBC6667 | - | - | - | - | 2 mm | - | - | - | 1 | €15.91 | |
 |
MPDBC6869 | - | - | - | - | 2 mm | - | - | - | 1 | €17.68 | |
 |
MPDB63101 | 600V AC/DC | Aluminum | 1 | 1 | 71.4 mm | Aluminum | #4 to #14 | Box | 1 | €11.13 | |
 |
MPDB63131 | 600V AC/DC | Aluminum | 1 | 4 | 71.4 mm | Aluminum | #14 AWG to 2/0 AWG | Box | 1 | €18.98 | |
 |
MPDB63132 | 600V AC/DC | Aluminum | 1 | 4 | 71.4 mm | Aluminum | #14 AWG to 2/0 AWG | Box | 1 | €33.19 | |
 |
MPDB63133 | 600V AC/DC | Aluminum | 1 | 4 | 71.4 mm | Aluminum | #14 AWG to 2/0 AWG | Box | 1 | €39.26 |
