MERSEN FERRAZ M403 Non Fused Disconnect, 600V, 40A, 3 Pole
Get it by Tuesday, Dec 23
€151.36 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Non-Fused Disconnect |
| Ac Voltage Rating | 600V |
| Ac/dc | AC |
| Connection/terminal Type | Box |
| Current Rating | 40A |
| Height | 45 mm |
| Installation Mounting | Direct Screw Mount |
| Length | 54.1 mm |
| Maximum Horsepower Rating/fla | 3 Phase 240V 10 Hp, 480V 20 Hp, 600V 25 Hp, 1 Phase 120V 2 Hp, 240V 5 Hp |
| Number Of Poles | 3 |
| Product Datasheet | mersen-ferraz-m163.pdf |
| Product Group | UL/CSA Switches |
| Rated Insulation Voltage | 750V |
| Rated Voltage Ac Ul | 600V |
| Rohs Compliant | Yes |
| Short Circuit Current Rating (sccr) | Up to 100 Ka With Fuses |
| Short Circuit Rating (class J) | 10 kA With 60A |
| Short Circuit Rating (class Rk5) | 5 kA With 60A |
| Torque Rating | 0.791 N-m |
| Width | 35.1 mm |
| Wiring Range | #18 to 8 |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 4.5 |
| Ship length (cm) | 5.41 |
| Ship width (cm) | 3.51 |
