MERSEN FERRAZ CNN80 Forklift Truck Fuse, 130VAC/75VDC, 80A
Item: CH4WNZModel: CNN80Cross Ref: 5LCK7
7 In Stock
Ships within 2 days via
10.00% off
€63.63 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Fuse |
| Ac Max I.r./breaking Capacity I1 | 2500A |
| Ac Voltage | 130V AC |
| Ac/dc | AC/DC |
| Amps | 80A |
| Body Material | Fiberglass |
| Body Style | Bolt On |
| Body/insulating Material | GMG |
| Connection/terminal Material | Copper |
| Connection/terminal Type | Blade |
| Dc Voltage Rating | 80V DC |
| Depth | 29/64" |
| Element | Single |
| Equivalent Brand And Series | Bussmann Ann, Littelfuse Cnn, Mersen Cnn |
| Equivalent Series | Ann, Cnn |
| Finish | Silver Plated |
| Fits Fuse Block Style | Nonrejection |
| Frequency | 50/60 Hz |
| Fuse Size | 3 3/16" x 3/4" x 29/64" |
| Height | 10.2 mm |
| Indication System | Yes |
| Indication System Type | Visual Indicator |
| Interrupt Rating | 2.5 kA @ 130V AC, 2.5 kA @ 80V DC |
| Length | 81 mm |
| Mounting | Bolted |
| Mounting Type | Bolted |
| Product Datasheet | mersen-ferraz-ack1.pdf |
| Product Group | Special Purpose Fuses |
| Rated Voltage Ac Ul | 130V |
| Rated Voltage Dc Ul | 80V |
| Rohs Compliant | Yes |
| Series | CNN Series |
| Speed | Very Fast Acting |
| Speed Characteristic | Fast Acting |
| Standards | Ul Recognized Component To Standard 248-1, File E60314 Jfhr2 |
| Visual Indication | Indicating |
| Width | 16.3 mm |
Shipping Info:
| Ship weight (kg) | 0.03 |
| Ship height (cm) | 1.63 |
| Ship length (cm) | 8.1 |
| Ship width (cm) | 1.63 |
| Country of Origin | CN |
Product Details:
- Blade Mount, Visual UL
Documentation:
Product Variants
| Model | Amps | Body Material | Fuse Size | Depth | Dc Voltage Rating | Speed | Visual Indication | Body Style | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| CNN10 | 10A | GMG | - | - | - | - | - | - | €41.20 | |
| CNN100 | 100A | Fiberglass | 3 3/16" x 3/4" x 29/64" | 29/64" | 80V DC | Very Fast Acting | Indicating | Bolt On | €70.70 | |
| CNN125 | 125A | Fiberglass | 3 3/16" x 3/4" x 29/64" | 29/64" | 80V DC | Very Fast Acting | Indicating | Bolt On | €70.72 | |
| CNN150 | 150A | Fiberglass | 3 3/16" x 3/4" x 29/64" | 29/64" | 80V DC | Very Fast Acting | Indicating | Bolt On | €69.00 | |
| CNN175 | - | Fiberglass | 3 3/16" x 3/4" x 29/64" | 29/64" | 80V DC | Very Fast Acting | Indicating | Bolt On | €77.11 | |
| CNN180 | 180A | GMG | - | - | - | - | - | - | €159.70 | |
| CNN200 | 200A | Fiberglass | 3 3/16" x 3/4" x 29/64" | 29/64" | 80V DC | Very Fast Acting | Indicating | Bolt On | €67.42 |
