MERSEN FERRAZ CNL40 Forklift Truck Fuse, 80VAC/VDC, 40A
Item: CH4WMRModel: CNL40Cross Ref: 5LCH7
7 In Stock
Ships within 2 days via
10.00% off
€67.45 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Fuse |
| Ac Max I.r./breaking Capacity I1 | 2500A |
| Ac Voltage Rating | 80V AC |
| Ac/dc | DC |
| Amps | 40A |
| Body Style | Bolt On |
| Body/insulating Material | GMG |
| Connection/terminal Material | Copper |
| Connection/terminal Type | Blade |
| Dc Voltage Rating | 80V DC |
| Depth | 13/32" |
| Element | Single |
| Equivalent Brand And Series | Bussmann Anl, Littelfuse Cnl, Mersen Cnl |
| Equivalent Series | Anl, Cnl |
| Finish | Silver Plated |
| Fits Fuse Block Style | Nonrejection |
| Frequency | 50/60 Hz |
| Fuse Size | 3 3/16" x 3/4" x 13/32" |
| Height | 10.2 mm |
| Indication System | Yes |
| Indication System Type | Visual Indicator |
| Interrupt Rating | 2.5 kA @ 80V AC, 2.5 kA @ 80V DC |
| Length | 81 mm |
| Mounting | Bolted |
| Mounting Type | Bolted |
| Product Datasheet | mersen-ferraz-ack1.pdf |
| Product Group | Special Purpose Fuses |
| Rated Voltage Dc Ul | 80V |
| Rohs Compliant | Yes |
| Series | CNL Series |
| Speed | Time Delay |
| Speed Characteristic | Time Delay |
| Standards | Ul Recognized Component To Standard 248-1, File E60314 Jfhr2 |
| Visual Indication | Indicating |
| Width | 16 mm |
Shipping Info:
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 1.6 |
| Ship length (cm) | 8.1 |
| Ship width (cm) | 1.6 |
| Country of Origin | CN |
Product Details:
- Blade Mount, Visual UL
Documentation:
Product Variants
| Model | Amps | Body Material | Ac Voltage Rating | Dc Voltage Rating | Speed | Visual Indication | Body Style | Mounting | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| CNL100 | 100A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €70.70 | |
| CNL125 | 125A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €75.15 | |
| CNL130 | 130A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €73.92 | |
| CNL150 | 150A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €41.20 | |
| CNL175 | 175A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €76.72 | |
| CNL200 | 200A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €70.70 | |
| CNL225 | 225A | Fiberglass | 80V AC | 80V DC | Time Delay | Indicating | Bolt On | Bolted | €75.13 |
