MARATHON MOTORS LM32778 SSD2B10TC61 General Purpose Motor, 10HP, 3600 RPM, 230/460V, 60Hz
Get it by Tuesday, Aug 25
€1,359.14 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | General Purpose Motor |
| Ambient Temp. | 40°C |
| Amps | 23.4/11.7/22/11A |
| Cc No. | CC004A |
| Design Code | B |
| Duty Cycle | Continuous |
| Eff 100% | 89.5 |
| Efficiency | 89.5%, 87.5% |
| Electrical Type | Squirrel Cage Induction Run |
| Enclosure | DP |
| Family Series | Leeson Miscellaneous |
| Frame | 213TC |
| Frame Length | 11.15" |
| Frame Material | Rolled Steel |
| Hertz | 1.2 |
| Hp | 10 hp |
| Insulation Class | Class F , F |
| Kw | 7.5 kW |
| Max. Amb | 40 |
| Motor Orientation | Horizontal |
| Motor Wt. | 116 lbs. |
| Mounting | Rigid |
| Nameplate | 81307 |
| No. Of Speeds | 1 |
| Opp Drive End Bearing Size | 6206 |
| Overall Length | 18.03" |
| Paint | 305249.01 |
| Phase | 3 |
| Pole | 2 |
| Product Datasheet | leeson-lm32778.pdf |
| Resistance Main | 1.1 ohms |
| Rotation | REV |
| Service Factor | 1.15 |
| Shaft Dia. | 1 3/8" |
| Shaft Extension | 3 3/25" |
| Shaft Type | T |
| Speed | 3515/2910 RPM , 3600 RPM |
| Thermal Protection | A-A56227-69 |
| Torque | Not Available |
| Type | Tdr |
| Voltage | 208-230V/460V |
| Winding | K213282 |
Shipping Info:
| Ship weight (kg) | 52.2 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| Country of Origin | MX |
Documentation:
