MARATHON MOTORS LM30095 SSD2P20/25T6006YEH2 Elevator Duty Motor, 20 and 25 HP, 3 Ph, 60 Hz, 200 and 200V, 3600 and 3600 RPM
Get it by Wednesday, Feb 25
€2,377.64 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Definite Purpose Motor |
| Ambient Temp. | 40°C |
| Cc Number | Exempt |
| Code | E |
| Design Code | B |
| Drive End Bearing Size | 309 |
| Drive End Bearing Type | Ball |
| Efficiency | 91% |
| Efficiency @ 100% | 91% |
| Enclosure Type | ODP |
| Frame | 254T |
| Frame Material | Rolled Steel |
| Frame Size | 254T |
| Frequency | 60 Hz |
| Full Load Amps | 68A |
| Grease Type | Polyrex EM |
| Hazardous Location | Not Available |
| Hp | 20 hp |
| Insulation Class | Class F |
| Kw | 14.9 kW |
| Lubrication | Standard |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Dripproof |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Squirrel Cage Induction Run |
| Mounting Type | Rigid |
| Nameplate Rpm | 3600 RPM |
| Nema Design | B, E |
| No. Of Poles | 2 |
| Opp. Drive End Bearing Size | 208 |
| Opp. Drive End Bearing Type | Ball |
| Outline | A-SS86503LN-1370 |
| Packaging | B |
| Paint | Lincoln Gray |
| Phase | 3 |
| Power | 14.9 kW |
| Power Factor | 88.6 |
| Protection | No Protection |
| Rotation Type | Reversible |
| Rpm | 3400-3600 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1 5/8" |
| Shaft Length | 4" |
| Speed Range | Not Available |
| Type | TDR |
| Voltage | 200V |
| Winding | K2152191 |
Shipping Info:
| Ship weight (kg) | 78.75 |
| Ship height (cm) | 35.56 |
| Ship length (cm) | 57.15 |
| Ship width (cm) | 42.7 |
| Country of Origin | US |
Product Details:
- Bearing OPE: 208
- CC Number: EXEMPT
- Bearing PE: 309
- Nameplate: 91554-39
- Winding: K2152191
- GROUP: 3
- Paint: GRAY - LINCOLN
- Eff 100%: 91 / 90.2
