MARATHON MOTORS LM24720 SS215F4S7.5T1B6008 General Purpose Motor, 7.50 HP, 1 Phase, 60 Hz, 208-230V, 1800 RPM
Get it by Thursday, Feb 26
€1,721.12 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Single Phase Motor |
| Ambient Temp. | 40°C |
| Amps | 102A |
| Assembly/box Mounting | F1 Only |
| Cc Number | Exempt |
| Code | G |
| Curvepoint | Break Down |
| Design Code | L |
| Drive End Bearing Size | 307 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 84% |
| Efficiency @ 100% | 84% |
| Electrical Type | Capacitor Start, Capacitor Run |
| Enclosure Type | Tefc |
| Frame | 215T |
| Frame Length | 12 2/5" |
| Frame Material | Rolled Steel |
| Frame Size | 215T |
| Frame Suffix | T |
| Frequency | 60 Hz |
| Full Load Amps | 30-35A |
| Hazardous Location | Not Available |
| Hp | 7 1/2 hp |
| Insulation Class | Class F |
| Ip Code | 43 |
| Kw | 5.6 kW |
| Load | 1 |
| Lubrication | Standard |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | Squirrel Cage Induction Run |
| Mounting Type | Rigid |
| Nameplate Rpm | 1800 RPM |
| Nema Design | G, L |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 206 |
| Opp. Drive End Bearing Type | Ball |
| Outline | A-SS88687LN-1240 |
| Output Kw | 5.6 kW |
| Overall Length | 21.09" |
| Packaging | B |
| Paint | Standard |
| Phase | 1 |
| Power Factor | 96 |
| Resistance Main | 0 ohms |
| Rotation Type | Selective CCW |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1 3/8" |
| Shaft Length | 3.38" |
| Shaft Type | T |
| Speed Range | Not Available |
| Starting Method | Across The Line |
| Synchronous Rpm | 1800 RPM |
| Thermal Protection | No Protection |
| Torque | 51 lbs.-ft. |
| Torquepct | 227 |
| Type | BFR |
| Voltage | 208-230V |
| Winding | BK104118 |
Shipping Info:
| Ship weight (kg) | 59.4 |
| Ship height (cm) | 35.56 |
| Ship length (cm) | 57.15 |
| Ship width (cm) | 42.7 |
| Country of Origin | MX |
Product Details:
- Eff 100%: 84
- Bearing OPE: 206
- CC Number: EXEMPT
- Bearing PE: 307
- Nameplate: 91554-9
- Winding: BK104118
- GROUP: 1
- Paint: VERIFY
