MARATHON MOTORS B199009.00 C213T34FB46A General Purpose Motor, 3 Phase, 3600 RPM, 230/460V, 7.5 HP
Get it by Tuesday, Aug 25
€1,146.01 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | General Purpose Motor |
| Amps | 18.4/9.2/15/7.5A |
| Amps Rating | 18.4/9.2A |
| Composition | Steel |
| Design Code | B |
| Dimension S | 18.35" x 13.07" x 10.99" |
| Drive End Bearing Size | 6307 |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Electrical Phase | 3 |
| Electrical Type | Squirrel Cage Inverter Rated |
| Enclosure | Totally Enclosed Fan Cooled |
| Enclosure Type | Totally Enclosed Fan Cooled (Tefc) |
| Family Series | Leeson Motors |
| Frame Length | 9.65" |
| Frequency | 60 Hz |
| Full Load Amps | 18.4A |
| Hp | 7 1/2 hp |
| Insulation Class | Class F |
| Kva Code | H |
| Kw | 5.6 kW |
| Motor Orientation | Horizontal |
| Mounting Type | Rigid Base |
| No. Of Speeds | 1 |
| Nominal Voltage | 240/480V AC |
| Opp Drive End Bearing Size | 6206 |
| Overall Length | 18.35" |
| Phase | 3 |
| Power Factor | 84.6 |
| Product Datasheet | leeson-b199009-00.pdf |
| Resistance Main | 1.635 ohms |
| Rotation | Reversible |
| Service Factor | 1.15 |
| Shaft Dia. | 1.375 |
| Shaft Extension | 3.38" |
| Shaft Length | 3.38 |
| Shaft Size | 1.38" x 3.38" |
| Shaft Type | T |
| Speed | 3400-3600 RPM , 3520 RPM |
| Thermal Protection | NO Protection |
| Torque Rating | 11.2 lbs.-ft. |
| Type | 2 Pole Continuous Duty |
| Variable Torque Speed Range | 10 |
| Voltage | 230/460V |
Shipping Info:
| Ship weight (kg) | 61.2 |
| Ship height (cm) | 35.56 |
| Ship length (cm) | 56.36 |
| Ship width (cm) | 41.91 |
| Country of Origin | CN |
