MACROMATIC TR-55128 Timer Relay 900 Second 8 Pin 10a Dpdt 24v
Item: AF7YUGModel: TR-55128Cross Ref: 23NV24
7 In Stock
Ships within 2 days via
5.00% off
€55.78 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Time Delay Relay |
| Adjustment Interface | Analog |
| Adjustment Method | Potentiometer |
| Amps | 10A |
| Base Type | Octal |
| Body Depth | 2.9" |
| Body Height | 1.7" |
| Body Width | 2.3" |
| Coil Rating | 2VA |
| Coil Rating | 2 VA |
| Coil Voltage | 24V AC/DC |
| Compatible With Grainger Part No | 1EGP3, 1EGP5, 5X852 |
| Contact Form | DPDT |
| Contact Material | Silver Nickel |
| Contact Rating (ac) | 10A @ 240V |
| Contact Rating (dc) | 10A @ 30V |
| Delay Function | Cycle On |
| Electrical Connection | Socket |
| Electrical Connection Type | Pin |
| Electrical Operating Durability | 100000 |
| Environmental Protection | Enclosed |
| Frequency | 50/60 Hz |
| Function | Repeat Cycle (On First) |
| Input Voltage | 24V AC/DC |
| Ip Rating | IP20 |
| Max. Operating Temp. | 122°F |
| Max. Time Setting | 15 min. , 900 sec. |
| Mechanical Operating Durability | 10000000 |
| Min. Operating Temp. | -18°F |
| Min. Time Setting | 9 sec. |
| Mounting | Plug In |
| No. Of Delay Functions | 1 |
| No. Of Pins/terminals | 8 |
| Operating Functions | 7 |
| Operating Time Accuracy | +0% -50% (Minimum Setting (Adjustable)), +2% 50Ms (Fixed), +5% -0% (Maximum Setting (Adjustable)) |
| Pins | 8 |
| Power Consumption | 2 VA |
| Relay Mounting Style | Socket |
| Reset Method | Time Limit Reset |
| Resistive Contact Amp Rating | 10A |
| Socket | 5X852, 1EGP3, 1EGP5 |
| Socket Code | A |
| Status Indicator | None |
| Status Indicator | No |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 10.67 |
| Ship length (cm) | 6.6 |
| Ship width (cm) | 5.08 |
| HS code | 8536490075 |
Product Variants
| Product | Model | Min. Time Setting | Max. Time Setting | Socket Code | Delay Function | Input Voltage | Ac Voltage | Adjustment Method | Coil Rating | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TR-50222-04 | 0.05 sec. | 5 sec. | A | On Delay | 120V AC/DC | - | Potentiometer | 2 VA | €46.19 | |
 |
TR-50222-10 | 1.8 sec. | 180 sec. | A | On Delay | 120V AC/DC | - | Potentiometer | 2 VA | €51.98 | |
 |
TR-50222-12 | 3 sec. | 5 min. | A | On Delay | 120V AC/DC | - | Potentiometer | 2 VA | €46.93 | |
 |
TR-50222 | 9 sec. | 15 min. | A | On Delay | 120V AC/DC | - | Potentiometer | 2 VA | €46.86 | |
 |
TR-50522-05 | 0.1 sec. | 10 sec. | A | Interval On | 120V AC/DC | - | Potentiometer | 2 VA | €48.42 | |
 |
TR-50522-10 | 1.8 sec. | 180 sec. | A | - | - | - | Potentiometer | 2 VA | €47.08 | |
 |
TR-50522-12 | 3 sec. | 5 min. | A | Interval On | 120V AC/DC | - | Potentiometer | 2 VA | €46.23 |
