MACROMATIC TR-55122 Timer Relay 900 Second 8 Pin 10a Dpdt 120v | AF7YUB 23NV19

MACROMATIC TR-55122 Timer Relay 900 Second 8 Pin 10a Dpdt 120v

Item: AF7YUBModel: TR-55122Cross Ref: 23NV19
7 In Stock

Ships within 2 days via

€58.72
10.00% off
€52.85 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Time Delay Relay
Adjustment Interface Analog
Adjustment Method Potentiometer
Base Type Octal
Body Depth 2.9"
Body Height 1.7"
Body Width 2.3"
Coil Rating 2VA
Coil Rating 2 VA
Coil Volts 120V AC/DC
Compatible With Grainger Part Number 1EGP3, 1EGP5, 5X852
Contact Form DPDT
Contact Material Silver Nickel
Contact Rating (ac) 10A @ 240V
Contact Rating (dc) 10A @ 30V
Current Rating 10A
Delay Function Cycle On
Electrical Connection Socket
Electrical Connection Type Pin
Electrical Operating Durability 100000
Environmental Protection Enclosed
Frequency 50/60 Hz
Function Repeat Cycle (On First)
Input Voltage 120V AC/DC
Ip Rating IP20
Max. Time Setting 900 sec.
Maximum Operating Temperature 122°F
Maximum Time Setting 15 min.
Mechanical Operating Durability 10000000
Min. Time Setting 9 sec.
Minimum Operating Temperature -18°F
Mounting Plug In
Number Of Delay Functions 1
Number Of Pins/terminals 8
Operating Functions 7
Operating Time Accuracy +0% -50% (Minimum Setting (Adjustable)), +2% 50Ms (Fixed), +5% -0% (Maximum Setting (Adjustable))
Pins 8
Power Consumption 2 VA
Relay Mounting Style Socket
Reset Method Time Limit Reset
Resistive Contact Amp Rating 10A
Socket 5X852, 1EGP3, 1EGP5
Socket Code A
Status Indicator No
Status Indicator None

Shipping Info:

Ship weight (kg) 0.11
Ship height (cm)10.92
Ship length (cm)6.6
Ship width (cm)4.83
HS code8536490075

Product Variants

ProductModelMax. Time SettingMin. Time SettingSocket CodeDelay FunctionInput VoltageNumber Of PinsAdjustment MethodCoil RatingPrice
MACROMATIC TR-50222-04 Timer Relay, 5 Sec, 8 Pin, 10A, 120V AC/DC | AB7KJV 23NU78 TR-50222-045 sec.0.05 sec.AOn Delay120V AC/DC8Potentiometer2 VA€46.19
MACROMATIC TR-50222-10 Timer Relay, 180 Sec, 8 Pin, 10A, 120V AC/DC | AB7KJW 23NU82 TR-50222-10180 sec.1.8 sec.AOn Delay120V AC/DC8Potentiometer2 VA€51.98
MACROMATIC TR-50222-12 Timer Relay, 5 Min., 8 Pin, 10A, 120V AC/DC | AB7KJX 23NU83 TR-50222-125 min.3 sec.AOn Delay120V AC/DC8Potentiometer2 VA€46.93
MACROMATIC TR-50222 Timer Relay 15 Min. 8 Pin 10a Dpdt 120v | AB7KJY 23NU84 TR-5022215 min.9 sec.AOn Delay120V AC/DC-Potentiometer2 VA€46.86
MACROMATIC TR-50522-05 Timer Relay, 10 Sec, 8 Pin, 10A, 120V AC/DC | AB7KJZ 23NU91 TR-50522-0510 sec.0.1 sec.AInterval On120V AC/DC8Potentiometer2 VA€48.42
MACROMATIC TR-50522-10 Timer Relay, 180 Sec, 8 Pin, 10A, 120V AC/DC | AB7KKA 23NU94 TR-50522-10180 sec.1.8 sec.A--8Potentiometer2 VA€47.08
MACROMATIC TR-50522-12 Timer Relay, 5 Min., 8 Pin, 10A, 120V AC/DC | AB7KKB 23NU95 TR-50522-125 min.3 sec.AInterval On120V AC/DC8Potentiometer2 VA€46.23
