MACROMATIC TR-51628 Timer Relay 900 Second 11 Pin 10a Dpdt 24v

Item: AF7YTWModel: TR-51628Cross Ref: 23NV12

7 In Stock

Ships within 2 days via

~~€47.56~~

10.00% off

€42.81 /unit

Add To Cart

Request a Quote

Payment

Product Specifications:

Item	Time Delay Relay
Adjustment Interface	Analog
Adjustment Method	Potentiometer
Base Type	Octal
Body Depth	2.9"
Body Height	1.7"
Body Width	2.3"
Coil Rating	2VA
Coil Rating	2 VA
Coil Volts	24V AC/DC
Compatible With Grainger Part Number	1EGP2, 1EGP4, 6X156
Contact Form	DPDT
Contact Material	Silver Nickel
Contact Rating (ac)	10A @ 240V
Contact Rating (dc)	10A @ 30V
Current Rating	10A
Delay Function	Off Delay
Electrical Connection	Socket
Electrical Connection Type	Pin
Electrical Operating Durability	100000
Environmental Protection	Enclosed
Frequency	50/60 Hz
Function	Off Delay
Input Voltage	24V AC/DC
Ip Rating	IP20
Max. Time Setting	900 sec.
Maximum Operating Temperature	122°F
Maximum Time Setting	15 min.
Mechanical Operating Durability	10000000
Min. Time Setting	9 sec.
Minimum Operating Temperature	-18°F
Mounting	Plug In
Number Of Delay Functions	1
Number Of Pins/terminals	11
Operating Functions	2
Operating Time Accuracy	+0% -50% (Minimum Setting (Adjustable)), +2% 50Ms (Fixed), +5% -0% (Maximum Setting (Adjustable))
Power Consumption	2 VA
Relay Mounting Style	Socket
Reset Method	Time Limit Reset
Resistive Contact Amp Rating	10A
Socket	6X156, 1EGP2, 1EGP4
Socket Code	B
Status Indicator	No
Status Indicator	None

Model	Max. Time Setting	Min. Time Setting	Socket Code	Delay Function	Input Voltage	Number Of Pins	Adjustment Method	Coil Rating	Price
TR-50222-04	5 sec.	0.05 sec.	A	On Delay	120V AC/DC	8	Potentiometer	2 VA	€46.19
TR-50222-10	180 sec.	1.8 sec.	A	On Delay	120V AC/DC	8	Potentiometer	2 VA	€51.98
TR-50222-12	5 min.	3 sec.	A	On Delay	120V AC/DC	8	Potentiometer	2 VA	€46.93
TR-50222	15 min.	9 sec.	A	On Delay	120V AC/DC	-	Potentiometer	2 VA	€46.86
TR-50522-05	10 sec.	0.1 sec.	A	Interval On	120V AC/DC	8	Potentiometer	2 VA	€48.42
TR-50522-10	180 sec.	1.8 sec.	A	-	-	8	Potentiometer	2 VA	€47.08
TR-50522-12	5 min.	3 sec.	A	Interval On	120V AC/DC	8	Potentiometer	2 VA	€46.23
