MACROMATIC THR-10566-34 Time Delay Relay, 12 VDC, 10A
Get it by Tuesday, Aug 25
€59.41 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Time Delay Relay |
| Ac Voltage | 240V AC |
| Adjustment Operator | Knob |
| Contact | SPDT |
| Contact Rating | 10A |
| Contact Rating (a) | 10A |
| Contacts | SPDT |
| Eu Rohs Indicator | Yes |
| Family Series | Macromatic Relays, THR Series |
| Gross Weight | 0 lbs. |
| Max. Time | 10 hrs. |
| Mounting Type | Surface |
| Multi-function | No |
| Output Amps | 10A |
| Series | THR Series |
| Termination | 0.25" Flat Blade |
| Time Range Adjustment | Onboard |
| Timer | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. |
| Timing Range | 0.1 - 10 Hours |
Shipping Info:
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 2.9 |
| Ship width (cm) | 5.08 |
| Country of Origin | US |
Product Variants
| Product | Model | Ac Voltage | Dc Voltage | Max. Time | Timer | Time Range 10 Hrs. | Output Amps | Amps | Mounting Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
THR-10261-04J | 240V AC | - | 5 sec. | - | - | 10A | - | Surface | €59.41 | |
 |
THR-10261-34 | 240V AC | - | 10 hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. | - | 10A | - | Surface | €59.41 | |
 |
THR-10261-34J | 240V AC | - | 10 hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. | - | 10A | - | Surface | €59.41 | |
 |
THR-10262-34 | 240V AC | - | 10 hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. | - | 10A | - | Surface | €59.41 | |
 |
THR-10262-34J | 240V AC | - | 10 hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. | - | 10A | - | Surface | €59.41 | |
 |
THR-10266-34 | 240V AC | - | 10 hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. | - | 10A | - | Surface | €59.41 | |
 |
THR-10266-34J | 240V AC | - | 10 hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs. | - | 10A | - | Surface | €59.41 |
