MACROMATIC TD-70528 Time Delay Relay, 24V AC/DC, 10A
Get it by Friday, Aug 14
€96.36 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Time Delay Relay |
| Ac Voltage | 24V AC |
| Adjustment Operator | Pushbutton Thumb Wheel |
| Contact | DPDT |
| Contact Rating | 10A |
| Contact Rating (a) | 10A |
| Contacts | DPDT |
| Dc Voltage | 24V DC |
| Eu Rohs Indicator | Yes |
| Family Series | Macromatic Relays, TD-7 Series |
| Gross Weight | 0 lbs. |
| Max. Time | 999 hrs. |
| Mounting Type | Socket |
| Multi-function | No |
| Output Amps | 10A |
| Series | TD-7 Series |
| Status Indicator | LED |
| Termination | 8 Pin |
| Time | 0 to 1, 0 to 2, 0 to 3, 0 to 5, 0 to 10, 0 to 15, 0 to 30, 0 to 60, 0 to 100 |
| Time Range 10 Hrs. | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs., 0 hr. to 20 hrs., 0 hr. to 30 hrs., 0 hr. to 100 hrs. |
| Time Range Adjustment | Onboard |
| Timer | 0 hr. to 1 hr., 0 hr. to 5 hrs., 0 hr. to 10 hrs., 0 hr. to 24 hrs., 0 hr. to 48 hrs., 0 hr. to 72 hrs., 0 hr. to 100 hrs. |
| Timing Range | 0.05 Seconds - 999 Hours |
| Voltage Ac | 24V AC |
Shipping Info:
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 6.1 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 4.32 |
| Country of Origin | US |
Product Variants
| Product | Model | Dc Voltage | Ac Voltage | Mounting Type | No. Of Pins | Output Amps | Max. Time | Contact Rating | Series | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TD-70221 | - | 240V AC | Socket | - | 10A | 999 hrs. | 10A | TD-7 Series | €103.29 | |
 |
TD-70222 | 120V DC | 120V AC | Socket | 8 | 10A | 999 hrs. | 10A | TD-7 Series | €96.36 | |
 |
TD-70224 | 48V DC | 48V AC | Socket | - | 10A | 999 hrs. | 10A | TD-7 Series | €103.29 | |
 |
TD-70226 | 12V DC | - | Socket | - | 10A | 999 hrs. | 10A | TD-7 Series | €96.36 | |
 |
TD-70228 | 24V DC | 24V AC | Socket | 8 | 10A | 999 hrs. | 10A | TD-7 Series | €96.36 | |
 |
TD-70521 | - | 240V AC | Socket | - | 10A | 999 hrs. | 10A | TD-7 Series | €103.29 | |
 |
TD-70522 | 120V DC | 120V AC | Socket | - | 10A | 999 hrs. | 10A | TD-7 Series | €96.36 |
