MACROMATIC CAP10AD68 AC Current Sensor, 5VA, Indicator Style LED, -40 to 85 Deg C
Item: CD6ETFModel: CAP10AD68Cross Ref: 485R28
7 In Stock
Ships within 2 days via
5.00% off
€129.37 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Current Sensing Relay |
| Amps | 10A |
| Amps Supported | 10A |
| Amps Unbalance Detect | No |
| Body Depth | 2.9" |
| Body Height | 2 2/5" |
| Body Width | 1.7" |
| Contact Failure Detect | No |
| Contact Form | SPDT |
| Contact Rating (ac) | 10A @ 240V |
| Contact Rating (dc) | 7A @ 28V |
| Control Voltage | 24V AC |
| Core Type | Internal |
| Electrical Connection | Pin , Terminal Strip |
| Electrical Connection Type | Pin |
| Electrical Operating Durability | 100000 |
| Electrical Phase | 3 |
| Frequency | 50/60 Hz |
| Function | Overcurrent AC/DC |
| Gross Weight | 0 lbs. |
| High Power Over Voltage Trip | No |
| Indicator Style | LED |
| Input Or Control Voltage | 24V AC |
| Input Voltage | 24V AC |
| Line Voltage | 24V |
| Lo Hp Trip Detect | No |
| Lo Kw Trip Detect | No |
| Lo Pwr (under Vltg) Trip | No |
| Load Capacity | 0-5 VA |
| Manual Reset | No |
| Max. Inrush Amps | 150A |
| Max. Operating Temp. | 149°F |
| Mechanical Operating Durability | 10000000 |
| Monitored Parameters | Overcurrent |
| Mounting Style | Plug-In |
| Mounting-relay | Plug In |
| No. Of Pins | 11 |
| No. Of Pins/terminals | 11 |
| Operating Life | 10000000 Operations |
| Output Relay | SPDT |
| Over Amps | No |
| Overall Depth | 3 1/2" |
| Phase Loss Detect | No |
| Phase Rvrse/rotatn Detect | No |
| Rapid Cycling Detect | No |
| Relay Mounting Style | Socket |
| Sensing Amps | 0.1-10A |
| Sensing Delay On Power | 0.1 sec. to 10 sec. |
| Sensing Delay On Power-up Ts | 0.1 sec. to 10 sec. |
| Sensor Opening | Internal |
| Series | Cap Series |
| Socket Code | B |
| Status Indicator | LED Indicator |
| Temp. | -40°C to +85°C |
| Trip Delay | 0.1 sec. to 10 sec. |
| Trip Delay Type | Fixed |
| Trip Point | 0.1/10A |
| Trip Point Type | Adjustable |
| Type Of Display | LED Status Indicator |
| Type Of Output | Relay |
| Under Amps Detect | No |
| Var Restart Delay | No |
| Variable Point Trip | No |
| Voltage Unbalance Detect | No |
Shipping Info:
| Ship weight (kg) | 0.2 |
| Ship height (cm) | 6.1 |
| Ship length (cm) | 7.37 |
| Ship width (cm) | 4.32 |
| Country of Origin | US |
Product Variants
| Product | Model | Electrical Connection | Input Voltage | Temp. | Load Capacity | Amps | Overall Depth | Body Depth | Body Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CAP10AD62 | Terminal Strip | 120V AC | -40°C to +85°C | 0-5 VA | 10A | 3 1/2" | 2.9" | 2 2/5" | €140.11 |
