LLAMBRICH USA JK-160 R-8 Keyless Drill Chuck 0.630 In
Item: AD8PJLModel: JK-160 R-8Cross Ref: 4LHH4
7 In Stock
Ships within 2 days via
5.00% off
€625.31 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | High Torque Drill Chuck |
| Accessory Type | High Torque With Intergrated Shank |
| Application | Drill Presses With High Accuracy, Jig Bore Machines, Mills Where The Application Requires Higher Feed Rates |
| Bearing Type | Plain |
| Capacity Min. | 0.118" |
| Chuck Dia. | 2.13" |
| Chuck Diameter | 2.13" |
| Chuck Type | Keyless |
| Chuck Type | High Torque |
| Closed Length | 3.86" |
| Construction | Steel |
| Drill Bit Shank Capacity (decimal Equivalent) | 0.125 to 0.625 |
| Drill Bit Shank Capacity (fractional Inch) | 1/8" to 5/8" |
| Features | Self-Tightening Mechanism Automatically Increases The Clamping Forces In Proportion To The Increase In Torque During The Drilling Operation |
| For Max. Drill Bit Shank Size | 5/8" |
| For Min Drill Bit Shank Size | 1/8" |
| Included | Wrench |
| Included Arbor | Arbor Included |
| Included Wrenches | Wrench Included |
| Keying | Keyless |
| Material | High Speed Steel |
| Material-machining | High Speed Steel |
| Max. Capacity | 0.63" |
| Max. Drill Capacity | 5/8" |
| Min. Capacity | 0.118" |
| Min. Drill Capacity | 1/8" |
| Mounting Size | R8 |
| Mounting Type | Integrated R8 Taper |
| Nominal Capacity | 5/8" |
| Open Length | 3.43" |
| Overall Length | 3.858" |
| Product Type | Drill Chuck |
| Series | JK-SOLID Series |
| Turn Direction | CW |
Shipping Info:
| Ship weight (kg) | 1.8 |
| Ship height (cm) | 8.13 |
| Ship length (cm) | 23.88 |
| Ship width (cm) | 9.14 |
| HS code | 8466100175 |
| Country of Origin | ES |
Product Variants
| Product | Model | Material | Mounting Size | Mounting Type | Max. Capacity | Min. Capacity | Drill Bit Shank Capacity (fractional Inch) | For Max. Drill Bit Shank Size | Drill Bit Shank Capacity (decimal Equivalent) | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
JK-08 MT-2 | Steel | 2MT | Integrated Morse Taper | 0.315" | 0.0" | 1/64" to 5/16" | 5/16" | 0.0156 to 0.3125 | €575.40 | |
 |
JK-10 MT-2 | Steel | 2MT | Integrated Morse Taper | 0.394" | 0.0" | 1/32" to 3/8" | 3/8" | 0.0312 to 0.375 | €559.74 | |
|
JK-13 MT-2 | Steel | 2MT | Integrated Morse Taper | 0.512" | 0.039" | 1/32" to 1/2" | 1/2" | 0.0312 to 0.5 | €589.04 | |
|
JK-13 MT-3 | Steel | 3MT | Integrated Morse Taper | 0.512" | 0.039" | 1/32" to 1/2" | 1/2" | 0.0312 to 0.5 | €622.88 | |
|
JK-13 MT-4 | Steel | 4MT | Integrated Morse Taper | 0.512" | 0.039" | 1/32" to 1/2" | 1/2" | 0.0312 to 0.5 | €635.82 | |
|
JK-130 R-8 | High Speed Steel | R8 | Integrated R8 Taper | 0.512" | 0.039" | 1/32" to 1/2" | 1/2" | 0.0312 to 0.5 | €594.69 | |
 |
JK-130 5/8 | High Speed Steel | 5/8" | Integrated Straight Shank | 0.512" | 0.039" | 1/32" to 1/2" | 1/2" | 0.0312 to 0.5 | €585.18 |
