LEESON LM33617 AF4B5TC65AP26 Voltage Motor, 5 HP, 3 Phase, 60 Hz, 575V, 1800 RPM
Get it by Tuesday, Aug 25
€1,124.43 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Voltage Motor |
| Design Code | B |
| Dimension S | 14.97" x 11.51" x 10.41" |
| Drive End Bearing Size | 6206 |
| Duty Cycle | Continuous |
| Efficiency | 89.8% |
| Electrical Type | Squirrel Cage Induction Run |
| Enclosure | Totally Enclosed Fan Cooled |
| Family Series | Leeson Motors |
| Frame Length | 9 1/2" |
| Height | 12 22/25" |
| Hp | 5 hp |
| Insulation Class | Class F |
| Kva Code | J |
| Kw | 3.7 kW |
| Length | 17.94" |
| Motor Orientation | Horizontal |
| Mounting Type | Rigid Base |
| Opp Drive End Bearing Size | 6205 |
| Overall Length | 14.97" |
| Phase | 3 |
| Power Factor | 83 |
| Product Datasheet | leeson-lm33617.pdf |
| Resistance Main | 2.68 ohms |
| Rotation | Reversible |
| Shaft Dia. | 1.125 |
| Shaft Extension | 2.91" |
| Shaft Length | 2.91 |
| Shaft Size | 1.125" x 2.91" |
| Shaft Type | T |
| Speed | 1700-1800 RPM |
| Thermal Protection | NO Protection |
| Type | 4 Pole Squirrel Cage Induction Run |
| Width | 13.06" |
Shipping Info:
| Ship weight (kg) | 46.8 |
| Ship height (cm) | 32.72 |
| Ship length (cm) | 45.57 |
| Ship width (cm) | 33.17 |
| Country of Origin | MX |
