LEESON LM25136 SRN4H0.25TCN61 Automotive Duty Motor, 0.25 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Dec 23
€84.26 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Definite Purpose Motor |
| Ambient Temp. | 65°C |
| Amps | 1.1/0.55A |
| Assembly/box Mounting | F1, F2 Capable |
| Cc Number | Exempt |
| Code | No |
| Code | N |
| Conduit Box Position | F1 |
| Design Code | B |
| Drive End Bearing Size | 203 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 70% |
| Electrical Type | Squirrel Cage, Induction Run |
| Enclosure Type | Tenv |
| Frame | 56C |
| Frame Length | 6.06" |
| Frame Material | Rolled Steel |
| Frame Size | 56C |
| Frequency | 60 Hz |
| Full Load Amps | 0.55A |
| Grease Type | Polyrex EM |
| Hazardous Location | Not Available |
| Hp | 1/4 hp |
| Insulation Class | Class F |
| Inverter Type | Not Available |
| Ip Code | 43 |
| Kw | 0.19 kW |
| Lubrication | Standard |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Squirrel Cage Induction Run |
| Mounting Type | Round |
| Nameplate Rpm | 1800 RPM |
| Nema Design | B, N |
| Nema Rating | NEMA 56 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 203 |
| Opp. Drive End Bearing Type | Ball |
| Outline | A-100104LN-606 |
| Output Kw | 0.19 kW |
| Overall Length | 9.94" |
| Packaging | B |
| Paint | Standard |
| Phase | 3 |
| Power | 0.187 kW |
| Power Factor | 60.5 |
| Resistance Main | 58.8 ohms |
| Rotation Type | Reversible |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Service Factor Amps | Not Available |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 22/25" |
| Speed Range | Not Available |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Type | TS |
| Voltage | 230/460V |
| Winding | ZT493 |
Shipping Info:
| Ship weight (kg) | 8.55 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 33.02 |
| Ship width (cm) | 19.69 |
| Country of Origin | MX |
Product Details:
- Eff 100%: 70
- Bearing OPE: 203
- CC Number: EXEMPT
- Bearing PE: 203
- Nameplate: 91554
- Winding: ZT493
- GROUP: 3
- Paint: GRAY (POWDER)
