LEESON 141275.00 Washdown Pump Motor, 3-Phase, 10 HP, 3, 525 Nameplate RPM, 230/460VAC, 215JM, 141275.00 | CR8PPU 798GE3

LEESON 141275.00 C215T34WK14A Washdown Pump Motor, 10/7.50 HP, 3 Phase, 60/50 Hz, 230/460 and 190/380V, 3600 RPM

Item: CR8PPUModel: 141275.00Cross Ref: 798GE3 / C215T34WK14A
Check Availability
In Stock

Get it by Tuesday, Dec 23

€7,441.39
10.00% off
€6,697.25 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item Washdown Motor
Ambient Temp. 40°C
Bearing Type Ball
Body Dia. 8 1/2"
Drive End Bearing Size 6209
Drive End Bearing Type Ball
Duty Cycle Continuous
Efficiency 90.2%
Enclosure Type Tefc
Finish Unfinished
Frame 215JM
Frame Material Stainless Steel
Frame Type 215JM
Frequency 60 Hz
Full Load Amps 23.6/11.8A
Hp 10 hp
Hz 60 Hz
Insulation Class Class F
Kw 7.5 kW
Max. Ambient Temp. 40°C
Motor Application Washdown
Motor Bearings Ball
Motor Design 3-Phase
Motor Enclosure Design Totally Enclosed Fan Cooled
Motor Frame Material Stainless Steel
Motor Mounting Position Horizontal
Motor Mounting Type Rigid Base
Motor Service Factor 1.15
Motor Shaft Design JM Threaded
Motor Shaft Rotation CW/CCW
Motor Type Three Phase
Mounting Type Rigid Base
Nameplate Rpm 3525 RPM
Nema Design B
No. Of Poles 2
No. Of Speeds 1
Nominal Efficiency 90.2%
Opp. Drive End Bearing Size 6207
Opp. Drive End Bearing Type Ball
Overall Length 19 13/16"
Phase 3
Product Type Washdown Motor
Rpm 3400-3600 RPM
Service Factor 1.15
Shaft Dia. 1 1/4"
Shaft Length 4 1/4"
Thermal Protection None
Voltage 230/460V
Weight 182 lbs.

Shipping Info:

Ship weight (kg) 81.9
Ship height (cm)36.2
Ship length (cm)57.48
Ship width (cm)40.97
Country of OriginMX

Product Variants

ProductModelVoltageNameplate RpmHpFull Load AmpsService FactorPhaseMounting TypeMotor TypePrice
LEESON 116466.00 Washdown Brake Motor, 3-Phase, 1/3 HP, 1, 725 Nameplate RPM, 208-230/460VAC, 56C | CR8PMF 48ZF09 116466.00208-230/460V1725 RPM33/100 hp0.65A1.153Face/BaseThree Phase€1,321.26
LEESON 122197.00 Washdown Brake Motor, 3-Phase, 2 HP, 1, 745 Nameplate RPM, 208-230/460VAC, 145TC | CR8PMG 48ZF15 122197.00208-230/460V1745 RPM2 hp2A1.153Rigid BaseThree Phase€2,541.76
LEESON 141427.00 Washdown Brake Motor, 3-Phase, 7 1/2 HP, 1, 750 Nameplate RPM, 230/460VAC, 215TZ | CR8PMH LM24804 141427.00230V1750 RPM7 1/2 hp26.4/13.2A1.153Rigid BaseThree Phase€1,864.33
LEESON 119458.00 Washdown Jet Pump Motor, 3-Phase, 1 1/2 HP, 3, 490 Nameplate RPM, 208-230/460VAC, 56J | CR8PPQ 48ZF59 119458.00208-230/460V3490 RPM1 1/2 hp4.4-4/2A1.153Face/BaseThree Phase€1,533.65
LEESON 119462.00 Washdown Jet Pump Motor, 3-Phase, 3 HP, 3, 490 Nameplate RPM, 208-230/460VAC, 56J | CR8PPR 48ZF66 119462.00208-230/460V3490 RPM3 hp8.8-8/4A1.153FaceThree Phase€1,599.38
LEESON 141358.00 Washdown Pump Motor, 3-Phase, 10 HP, 3, 495 Nameplate RPM, 230/460VAC, 213JM | CR8PPT 798GD5 141358.00230/460V3495 RPM15 hp35/17.6A1.153Rigid BaseThree Phase€5,484.32
LEESON 141273.00 Washdown Pump Motor, 3-Phase, 7 1/2 HP, 1, 765 Nameplate RPM, 230/460VAC, 215JM, 141273.00 | CR8PPV 798GE2 141273.00230/460V1765 RPM7 1/2 hp19.6/9.8A1.153Rigid BaseThree Phase€4,624.15
