JOHNSON CONTROLS A421AET-01C Electronic Temp Control 40 to 212 F Grey
Item: AH4VAMModel: A421AET-01CCross Ref: 35LY85
7 In Stock
Ships within 2 days via
10.00% off
€301.97 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Electronic Temperature Control |
| Ambient Humidity | 0% rh to 95% rh |
| Application | Boiler Control, Chiller Control, Cooling Control, Damper Control, Fan Control, Heating Control, Temperature Sensing And Control |
| Color | Gray |
| Compatible With Series | A99 Series |
| Contact Form | SPDT |
| Contact Type | SPDT |
| Control Range | -40°F to +212°F |
| Depth | 2 3/8" |
| Differential | +1°F to +30°F |
| Display Color | Gray |
| Display Color | Black\White |
| Display Height | 1 1/2" |
| Display Size | 1.5 x .5 sq. in. |
| Display Type | Digital |
| Display Width | 1/2" |
| Full Load Amps @ 120v | 16A |
| Full Load Amps @ 240v Ac | 8A |
| Full Load Amps @ 240vac | 8A |
| Height | 5" |
| Horsepower @ 120v Ac | 1 hp |
| Horsepower @ 240v Ac | 1 hp |
| Housing Material | Steel |
| Includes | Integral Cycle Timer |
| Input Voltage | 120/240V AC |
| Ip Rating | IP67 |
| Maximum Control Temperature | 212°F |
| Maximum Temperature Differential Setting | 30°F |
| Minimum Control Temperature | -40°F |
| Minimum Temperature Differential Setting | 1°F |
| Nema Rating | 4X |
| Nema/ip Rating | 4X/Nema Ip67 |
| No. Of Contacts | 1 |
| No. Of Sensor Inputs | 1 |
| No. Of Sensors Included | 1 |
| Number Of Relay / Analog Outputs | 1 Relay |
| Number Of Relay Inputs | 1 |
| Number Of Relay Outputs | 1 |
| Number Of Spdt Outputs | 1 |
| Number Of Stages | 1 |
| Overall Depth | 2 3/8" |
| Overall Height | 5" |
| Overall L X W | 5" x 2 3/8" |
| Overall Width | 2 3/8" |
| Power Consumption | 1.8 VA |
| Product Datasheet | johnson-controls-a421abc-02c.pdf |
| Product Type | Temperature Control |
| Sensing Bulb Dia. | 1/4" |
| Sensing Bulb Length | 2" |
| Sensor Type | A99BB-25C |
| Switch Action | Open/Close On Rise |
| Switch Type | SPDT |
| Temperature Control Function | Heat And Cool |
| Variable Output Voltage | No |
| Width | 2 3/8" |
Shipping Info:
| Ship weight (kg) | 0.58 |
| Ship height (cm) | 12.7 |
| Ship length (cm) | 6.03 |
| Ship width (cm) | 6.03 |
| Country of Origin | MX |
Documentation:
Product Variants
| Model | Sensor Type | Input Voltage | Power Consumption | Display Type | Height | Color | Differential | Number Of Relay Inputs | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| A421ABC-02C | A99BB 200C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €195.83 | |
| A421ABC-03C | A99BB 300C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €201.92 | |
| A421ABC-04C | A99BB 400C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €204.62 | |
| A421ABC-06C | A99BB 400C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €211.89 | |
| A421ABT-02C | A99BB 200C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €226.42 | |
| A421ABD-02C | A99BB 200C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €221.23 | |
| A421ABG-02C | A99BB 200C | 120/240V AC | 1.8 VA | Digital | 5" | Gray | +1°F to +30°F | 1 | €268.70 |
