INSIZE 3220-3 Mechanical Caliper-Jaw Inside Micrometer, Inch to Inch Range, +/-0.00036 Inch Accuracy
Item: CR4TKNModel: 3220-3Cross Ref: 462U58
7 In Stock
Ships within 2 days via
10.00% off
€247.31 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Inside Micrometer |
| Accuracy | -0.00036" to +0.00036" |
| Anvil | Curved |
| Anvil Material | Carbide |
| Case Type | Plastic Case |
| Contact Point Material | Carbide |
| Contact Point Shape | Curved |
| Features | Carbide Measuring Faces |
| Included Certification | Inspection Certificate |
| Includes Case | Yes |
| Inside Micrometer Type | Caliper Micrometer |
| Lock Nut Type | Spindle Locking Nut |
| Max. Measurement | 3" |
| Maximum Measurement | 3" |
| Maximum Measuring Depth | 0.197" |
| Min. Measurement | 2" |
| Minimum Measurement - Inch | 2" |
| Movement Of Screw | 1" |
| Number Of Gauges | 1 |
| Number Of Measuring Rods | 0 |
| Number Of Micrometers | 1 |
| Operation Type | Mechanical |
| Range | 2" to 3" |
| Resolution | 0.001" |
| Rod Type | Adjustable |
| Rotating Spindle | No |
| Spc Output | No |
| Spindle | Curved |
| Spindle Material | Carbide |
| Thimble | Ratchet |
| Thimble Type | Ratchet |
Shipping Info:
| Ship weight (kg) | 0.36 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Model | Range | Spindle Material | Contact Point Shape | Maximum Measurement | Maximum Measuring Depth | Min. Measurement | Spindle | Resolution | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 3220-1 | 0.2" to 1.2" | Carbide | Curved | 1 1/5" | 0.197" | 1/5" | Curved | 0.001" | €224.30 | |
| 3238-2 | 1" to 2" | Steel | Flat | 2" | 0.295" | 1" | Flat | 0.001" | €479.32 | |
| 3220-2 | 1" to 2" | Carbide | Curved | 2" | 0.197" | 1" | Curved | 0.001" | €239.19 | |
| 3238-1 | 0" to 1" | Steel | Flat | 1" | 0.295" | 0.0" | Flat | 0.001" | €402.31 | |
| 3220-4 | 3" to 4" | Carbide | Curved | 4" | 0.197" | 3" | Curved | 0.001" | €309.37 |
