ICM ICM493 Surge Protective Device Single Phase
Item: AG2XHQModel: ICM493Cross Ref: 32MY19
7 In Stock
Ships within 2 days via
5.00% off
€591.91 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Surge Protective Device |
| % Voltage Unbalance | 5% to 10% |
| Contact Rating | 40A |
| Control Voltage | 240V |
| Control Volts | 240 |
| Delay Type | Anti Short Cycle |
| Depth | 8" |
| Frequency | 50/60 Hz |
| Height | 4" |
| Max. Control Voltage | 240V AC |
| Max. Operating Temp. | 167°F |
| Max. Voltage Measurement | 264V AC |
| Min. Contol Voltage | 24V AC |
| Min. Operating Temp. | -40°F |
| Min. Voltage Measurement | 180V AC |
| Monitored Measurements | High Power Surges, Over And Under Voltage, Rapid Short Cycling |
| Mounting Type | Surface |
| Normally Open Output Amps | 40A |
| Overall Height | 4 3/8" |
| Overall Length | 8" |
| Overall Width | 8 1/4" |
| Phase | 1 |
| Programmable | Programmable |
| Reset Type | Automatic Reset |
| Response Time | 100 ms |
| Temp. | -4°F to +158°F |
| Temp. Rating | -4 to 158 F |
| Time Delay | 0.5 min. to 10 min. |
| Type | Single Phase |
| Voltage | 200-300V |
| Width | 8" |
Shipping Info:
| Ship weight (kg) | 3.63 |
| Ship height (cm) | 14.73 |
| Ship length (cm) | 23.62 |
| Ship width (cm) | 23.37 |
| HS code | 9032906080 |
Product Details:
- Delay (Button Adjustable)
- Monitors (Over and Under Voltage, Rapid Short Cycling, High Power Surges)
- N.O. Output (Amps) (40)
