HUMBOLDT H-4205 Soil Penetrometer, Dial Type

Humboldt H-4205 pocket penetrometer determines the unconfined compressive strength of foundations made of materials ranging from clay to sandy soils. Using the reference chart (included), readings obtained with this device can be used to estimate safe bearing pressures. This penetrometer can also indicate an angle of internal friction (sandy soils).

Features:

• Humboldt H-4205 offers +/-1% full scale accuracy at 20 degrees Celsius (68 degrees Fahrenheit).
• The outer dial measures the penetration force in kg, while the inner dial measures the unconfined compressive strength for the 0.25-inch plunger tip in kg/sq.cm, which equates to TSF.
• The device also includes plungers with diameters of 10, 15, 20 and 25 mm that can be used to measure strength in a variety of cohesive soil types.
• The 2.5-inch-diameter dial can be easily recalibrated using register plates (included) and any readable scale with a capacity of 10 - 15 lb.
• It includes data tables, register plates, instructions and a carrying case.

Standards and Approvals:

• OSHA

Frequently Asked Questions:

Q. Which plunger tip is to be used with different types of soil?

A.

• Use the 20 or 25 mm plunger tip for sandy soil, which has high internal friction but little cohesion.
• Use the 10 or 15 mm plunger tip for clayey soil with cohesion but a low angle of internal friction.
• Using the included chart, you can calculate soil cohesion at various forces, as well as additional determinations.
