HUBBELL WIRING DEVICE-KELLEMS HBLS4100C7W Straight Blade Connector, 100A, 480V AC
Get it by Friday, Feb 20
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
5.00% off
€3,466.49 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Straight Blade Connector |
| Cap Type | Spring Loaded Cap |
| Compatible With Series | Advantage Series |
| Connection Orientation | Straight |
| Contact Material | Brass |
| Current Rating | 100A |
| Features | Spring Loaded Disconnect Button |
| For Maximum Cable Diameter | 1.94" |
| For Minimum Cable Diameter | 0.9" |
| Grounding | Grounded |
| Grounding Style | IEC |
| Horsepower Rating | 40 hp |
| Housing Color | Red |
| Housing Material | PBT |
| Ip Rating | IP68, IP69K |
| Market | Industrial |
| Maximum Operating Temperature | 75°C |
| Maximum Wire Size | 1 AWG |
| Minimum Operating Temperature | -40°C |
| Minimum Wire Size | 6 AWG |
| Nema Enclosure Rating | NEMA 4X |
| Number Of Poles | 3 |
| Number Of Wires | 4 |
| Outside Diameter | 5.63" |
| Overall Length | 15.89" |
| Phase | Three |
| Power Indicating Light | Yes |
| Product Datasheet | hubbell-wiring-device-kellems-hbls4100c7w.pdf |
| Resistance Properties | Corrosion Resistant, Impact Resistant, Watertight |
| Reverse Service | No |
| Shrouded | Yes |
| Switch Rated | Yes |
| Ul 94 Flammability Rating | V-0 |
| Voltage Rating | 480V AC |
| Wire Connection Type | Screw Terminals |
Shipping Info:
| Ship weight (kg) | 2.48 |
| Ship height (cm) | 14.3 |
| Ship length (cm) | 40.36 |
| Ship width (cm) | 14.3 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Current Rating | Voltage Rating | Number Of Poles | Number Of Wires | Housing Color | Ip Rating | Housing Material | Power Indicating Light | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
515C | 15A | 125V AC | 2 | 3 | Black | IP20 | Nylon | No | €23.82 | |
 |
HBLS4100C12W | 100A | 125/250V AC | 3 | 4 | Orange | IP68, IP69K | PBT | Yes | €4,311.69 | |
 |
HBLS4100C5W | 100A | 600V AC | 3 | 4 | Black | IP68, IP69K | PBT | Yes | €5,233.63 | |
|
HBLS4100C6W | 100A | 380-415V AC | 3 | 4 | Red | IP68, IP69K | PBT | Yes | €4,815.53 | |
 |
HBLS4100C9W | 100A | 250V AC | 3 | 4 | Blue | IP68, IP69K | PBT | Yes | €4,446.84 | |
|
HBLS5100C5W | 100A | 347/600V AC | 4 | 5 | Black | IP68, IP69K | PBT | Yes | €5,200.12 | |
|
HBLS5100C6W | 100A | 200/346-240/415V AC | 4 | 5 | Red | IP68, IP69K | PBT | Yes | €5,200.12 |
