HUBBELL WIRING DEVICE-KELLEMS HBL5461I Straight Receptacle, 20A 250V, 6-20R, Ivory
Item: AE7LFHModel: HBL5461ICross Ref: 5Z833
7 In Stock
Ships within 2 days via
5.00% off
€78.03 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Receptacle |
| Afci | No |
| Amps | 20A |
| Application Environment | Heavy Use Industrial/Harsh Environments |
| Color | Ivory |
| Connection Orientation | Straight |
| Connectivity | Back And Side Wired Screw Terminals |
| Contact Material | Brass |
| Cover Type | No Cover |
| Dielectric Strength | Withstands 2,000V minimum |
| Duty | Extra Heavy |
| Face Dia. | 1.4" |
| Face Plate Height | 1.9" |
| Face Plate Width | 1.7" |
| Gfci | No |
| Grade | Federal Specification |
| Grounding | Grounded |
| Height | 1.19" |
| Housing Color | Ivory |
| Housing Material | Nylon |
| Hp | 2 hp |
| Included | Grounding Clip, Mounting Hardware |
| Included Mounting Hardware | Yes |
| Length | 3 7/25" |
| Material | Nylon |
| Max. Hp | 2 hp |
| Max. Operating Temp. | 167°F |
| Max. Wire Size | 10 AWG |
| Min. Operating Temp. | -40°F |
| Min. Wire Size | 12 AWG |
| Mount Hole Center To Center Height | 3.3" |
| Mounting Type | Flush |
| Nema Enclosure Rating | 1 |
| Nema Rating | NEMA 6-20R |
| Nema Receptacle Configuration | Nema 6-20R |
| No. Of Gangs | 1 |
| No. Of Poles | 2 |
| No. Of Wires | 3 |
| Outlet Type | Single |
| Overall Depth | 1.2" |
| Phase | 1 |
| Polarized | Yes |
| Power Indicator | No |
| Product Datasheet | hubbell-wiring-device-kellems-hbl5461i.pdf |
| Receptacle Type | Single |
| Signal & Power Protection | Standard Protection |
| Surge Protection | No |
| Ul 94 Flammability Rating | V-0, V-2 |
| Voltage | 250V , 250V AC |
| Wattage | 5000 W |
| Watts | 5000 W |
| Weather Resistance | No |
| Weather Resistant | No |
| Width | 1.63" |
| Wire Connection Location | Back, Side |
| Wire Connection Type | Screw Terminal |
| Wire Size | 12 AWG to 10 AWG |
| Wiring Method | Back And Side |
Shipping Info:
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 3.02 |
| Ship length (cm) | 8.33 |
| Ship width (cm) | 4.14 |
| HS code | 8536698000 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Color | Amps | Wire Size | Watts | Voltage | Max. Hp | Material | Grade | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL5261 | Brown | 15A | 14 AWG to 10 AWG | 1875 W | 125V AC | 1/2 hp | Nylon, Reinforced PET | Federal Specification | €57.51 | |
 |
HBL5361 | Brown | 20A | 12 AWG to 10 AWG | 2500 W | - | - | Nylon, Reinforced PET | Grade Industrial | €86.52 | |
 |
HBL5461 | Brown | 20A | 12 AWG to 10 AWG | 5000 W | 250V AC | 2 hp | Nylon, Reinforced PET | Federal Specification | €85.21 | |
 |
HBL5661 | Brown | 15A | 12 AWG to 10 AWG | 3750 W | 250V AC | 1 1/2 hp | Nylon, Reinforced PET | Federal Specification | €67.62 | |
 |
HBL5361GRYWR | Gray | 20A | 12 AWG to 10 AWG | 2500 W | 125V AC | - | Nylon, Reinforced PET | Federal Specification | €65.58 | |
 |
HBL5361IWR | Ivory | 20A | 12 AWG to 10 AWG | 2500 W | 125V AC | - | Nylon, Reinforced PET | Federal Specification | €65.58 | |
 |
HBL5361WR | Brown | 20A | 12 AWG to 10 AWG | 2500 W | 125V AC | 1 hp | Nylon, Reinforced PET | Federal Specification | €73.42 |
