HUBBELL WIRING DEVICE-KELLEMS H320R Straight Blade Receptacle, 16A 250V, Pressure Screw Terminal, Black
Item: AD7AQXModel: H320RCross Ref: 4D260
7 In Stock
Ships within 2 days via
5.00% off
€36.77 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Female Receptacle |
| Afci | No |
| Amps | 16/20A |
| Application Environment | Industrial Environments |
| Color | Black |
| Connection Orientation | Straight |
| Connectivity | Screw Terminals |
| Contact Material | Brass |
| Cover Type | No Cover |
| Dielectric Strength | Withstands 2,000V minimum |
| Face Plate Height | 1.5" |
| Gfci | No |
| Grade | General Use |
| Grounding | Grounded |
| Height | 1 13/25" |
| Housing Color | Black |
| Housing Material | Nylon |
| Included | Mounting Hardware |
| Ip Rating | IEC |
| Length | 1.41" |
| Material | Nylon |
| Max. Operating Temp. | 167°F |
| Max. Wire Size | 12 AWG |
| Min. Operating Temp. | -40°F |
| Min. Wire Size | 16 AWG |
| Mount Hole Center To Center Width | 1.9" |
| Mounting Location | Panel |
| Mounting Type | Flush , Panel |
| Nema Configuration | Non NEMA |
| Nema Enclosure Rating | 1 |
| Nema Rating | Non NEMA |
| No. Of Gangs | 1 |
| No. Of Poles | 2 |
| No. Of Wires | 3 |
| Outlet Type | Single |
| Overall Depth | 1.5" |
| Phase | 1 |
| Polarized | Yes |
| Power Indicator | No |
| Product Datasheet | hubbell-wiring-device-kellems-h320r.pdf |
| Receptacle Type | Single |
| Signal & Power Protection | Standard Protection |
| Special Resistance Properties | Impact Resistant |
| Surge Protection | No |
| Ul 94 Flammability Rating | V-0 |
| Voltage | 250V , 250V AC |
| Wattage | 7500 W |
| Watts | 7500 W |
| Weather Resistance | No |
| Weather Resistant | No |
| Width | 1.89" |
| Wire Connection Location | Back |
| Wire Connection Type | Screw Terminal |
| Wire Size | #16 AWG to #12 AWG, 1.55 sq. mm to 2.5 sq. mm |
| Wiring Method | Terminal Screws |
Shipping Info:
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 3.86 |
| Ship length (cm) | 3.58 |
| Ship width (cm) | 4.8 |
| HS code | 8536698000 |
| Country of Origin | US |
