HUBBELL WIRING DEVICE-KELLEMS CS8265C Male Plug, 50A, 250V, 2-Pole, 3-Wire Grounding
Item: AC8QGEModel: CS8265CCross Ref: 3D331
7 In Stock
Ships within 2 days via
5.00% off
€245.57 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Locking Plug |
| Amps | 50A |
| Anti Microbial | No |
| Blade Material | Brass |
| Body Length | 6.37" |
| Cable Range | 0.83" to 1.25" |
| Color | Black, White |
| Connection Orientation | Straight |
| Connectivity | Pressure Terminal Screws |
| Cord Dia. Range | 0.830"-1.250" |
| Cord Size | 0.75" to 1.125" |
| Dielectric Strength | Withstands 2,000V minimum |
| For Environment | Dry |
| For Location | Indoor |
| For Max. Cable Dia. | 1.25" |
| For Min. Cable Dia. | 0.83" |
| Grade | Grade Industrial |
| Grounding | Grounded |
| Height | 2 14/25" |
| Housing Color | Black, White |
| Housing Material | Nylon |
| Ip Rating | IP20 |
| Length | 6.37" |
| Market | Industrial |
| Material | Nylon |
| Max. Operating Temp. | 75°C |
| Max. Wire Size | 6 AWG |
| Min. Operating Temp. | -40°C |
| Min. Wire Size | 10 AWG |
| Mounting | Cord Mounted |
| Nema Configuration | Non NEMA |
| Nema Plug Configuration | Non NEMA |
| No. Of Blades | 3 |
| No. Of Poles | 2 |
| No. Of Wires | 3 |
| Outside Dia. | 2.563" |
| Overall Length | 6.37" |
| Phase | 1 |
| Polarized | Yes |
| Product Datasheet | hubbell-wiring-device-kellems-cs8265c.pdf |
| Resistance Properties | Chemical Resistant, Impact Resistant |
| Shrouded | Yes |
| Type | Shrouded |
| Ul 94 Flammability Rating | HB |
| Voltage | 250V , 250V AC |
| Wattage | 12500 W |
| Watts | 12500 W |
| Width | 2 14/25" |
| Wire Connection Type | Screw Terminal |
| Wire Size | #10 AWG to #6 AWG |
| Wiring Style | Standard |
| Wiring Type | Standard |
Shipping Info:
| Ship weight (kg) | 0.56 |
| Ship height (cm) | 6.5 |
| Ship length (cm) | 16.18 |
| Ship width (cm) | 6.5 |
| HS code | 8536698000 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Phase | Wiring Style | Shrouded | Housing Color | Ip Rating | Wire Size | Material | Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL2351 | 1 | Standard | No | Black, White | IP20 | 16 AWG to 8 AWG | Nylon | 2 3/4" | €51.19 | |
 |
HBL26419 | 3 | Standard | Yes | Yellow | IP30 | #8 AWG to #4 AWG | Nylon | 5.9" | €1,030.56 | |
 |
HBL2761 | 3 | Standard | No | Black, White | IP20 | 16 AWG to 8 AWG | Nylon | 2 3/4" | €103.89 | |
 |
HBL3763C | 1 | Standard | Yes | Black, White | IP20 | 8 AWG to 4 AWG | Nylon | 6.37" | €272.68 | |
 |
HBL3765C | 1 | Standard | Yes | Black, White | IP20 | 8 AWG to 4 AWG | Nylon | 6.37" | €327.43 | |
 |
HBL7567C | 1 | Standard | No | Black, White | IP20 | 18 AWG to 10 AWG | Nylon | 1.97" | €61.65 | |
 |
HBL7765C | 1 | Standard | Yes | Black, White | IP20 | 8 AWG to 4 AWG | Nylon | 6.37" | €267.60 |
