HONEYWELL V7-1B17D8-122 Premium Mini Switch 3a Spdt Short Straight Lever
Item: AB7TNRModel: V7-1B17D8-122Cross Ref: 24A244
7 In Stock
Ships within 2 days via
5.00% off
€7.43 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Premium Miniature Snap Switch |
| Ac Contact Rating | 11A @ 250V |
| Actuation Type | Short Straight Lever |
| Actuator Length | 1.63" |
| Actuator Style | Lever |
| Actuator Type | Short Straight Lever |
| Actuator Type-snap Action Switch | Lever, Short |
| Amps | 3A |
| Body Depth | 0.4" |
| Body Height | 0.63" |
| Body Material | Polyester |
| Body Width | 1.14" |
| Center Mounting Hole Distance | 0.88" |
| Dc Contact Rating | 0.25A @ 250V, 0.5A @ 125V |
| Depth-snap Action Switch | 2/5" |
| Differential Travel | 0.053" |
| Display Qty | 1 |
| Electrical Connection | Quick Connect |
| Height | 0.63" |
| Height-snap Action Switch | 0.63" |
| Length | 1.14" |
| Lever Actuator Length | 1.63" |
| Lever Actuator Length-snap Action Switch | 1.63" |
| Max. Differential Travel | 0.053" |
| Max. Operating Force | 1.5 ozf |
| Max. Operating Temp. | 365°F |
| Max. Pretravel | 6 mm |
| Min. Operating Temp. | -40°F |
| Mounting Dimensions | 0.41" x 0.87" |
| Mounting Hole Dia. | 1/8" |
| No. Of Contact Form | 2 , NO/NC |
| Operating Force | 0.42N |
| Operating Temp. | -40°F to +180°F |
| Over Travel | 0.118" |
| Overall Depth | 0.4" |
| Overall Height | 0.63" |
| Overall Width | 1.14" |
| Pre-travel | 0.236" |
| Release Force | 0.1 ozf |
| Series | V7 Series |
| Voltage | 250V AC |
| Watertight | No |
Shipping Info:
| Ship height (cm) | 3.56 |
| Ship length (cm) | 10.16 |
| Ship width (cm) | 9.91 |
| HS code | 8536509055 |
| Country of Origin | MX |
Product Variants
| Product | Model | Amps | Actuator Length | Lever Actuator Length-snap Action Switch | Voltage | Lever Actuator Length | Actuator Style | No. Of Contact Form | Ac Contact Rating | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
V7-1B17D8-022 | 10A | 1.41" | 1.41" | 277V AC | 1.41" | Roller Lever | NO/NC | 11A @ 277V | €7.26 | |
 |
V7-1C17D8-002 | 15A | 0.87" | 0.87" | 277V AC | 0.87" | Roller Lever | NO/NC | 15A @ 125V | €8.26 |
