HAYWARD DAB1020UFF Diaphragm Valve 2-way 2 Inch Fnpt x Socket
Item: AC9MXCModel: DAB1020UFFCross Ref: 3HMD3
7 In Stock
Ships within 2 days via
10.00% off
€776.92 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Diaphragm Valve |
| Ambient Temp. Range | 0°F to +140°F |
| Ambient Temperature - Maximum | 140°F |
| Ambient Temperature - Minimum | 0°F |
| Body Material | PVC |
| Coefficient Of Volume | 48 |
| Coefficient Of Volume(cv) | 56 |
| Connection Type | NPT x Socket |
| Connection Type - Side 2 | Socket |
| Connection Type-side 1 | NPT |
| Diaphragm Material | FPM |
| Fluid Temp. Range | 40 Degrees to 140 Degrees F |
| Fluid Temp. Range | +40°F to +140°F |
| For Media | Chemicals |
| Handle Height | 8.27" |
| Handle Type | Wheel |
| Length | 8.27" |
| Manufacturer Warranty | 3 yrs. |
| Max. Operating Temperature | 140°F |
| Max. Pressure | 150 psi |
| Media Temperature Range | 34°F to 140°F |
| Min. Operating Temperature | 34°F |
| Nominal Valve Size | 2" |
| Pipe Size | 2" |
| Seal Material | FPM |
| Special Features | Position Indicator |
| Standards | Astm D1784 |
| Valve Series | DAB Series |
| Valve Ways | 2-Way |
Shipping Info:
| Ship weight (kg) | 4.14 |
| Ship height (cm) | 17.53 |
| Ship length (cm) | 21.01 |
| Ship width (cm) | 37.08 |
| HS code | 8481805090 |
| Country of Origin | KR |
