HARRIS 3002494 Specialty Gas Regulator, Single Stage, CGA-510, 0 to 15 psig, Use With Acetylene
Request a Quote
Payment
Delivery
Product Specifications:
| Application | Industrial Purpose |
| Body Finish | Chrome Plated |
| Body Material | Brass |
| Control Type | T Handle |
| Delivery Pressure | 0 psig to 15 psig |
| Diaphragm Material | Stainless Steel |
| Inlet | CGA 510-0.965"-14-NGO-Female-Left Hand |
| Inlet Connection | Cga510 |
| Inlet Connection Gender | Female |
| Inlet Connection Type | Ngo |
| Inlet Thread Direction | Left Hand |
| Inlet Type | Ngo Female Left Hand Inlet |
| Max. Inlet Pressure | 500 psig |
| Max. Outlet Pressure | 15 psig |
| Outlet Connection | 9/16"-18 M LH |
| Outlet Connection Type | UNF |
| Outlet Pressure | 0 psig |
| Outlet Type | UNF Left Hand Outlet |
| Overall Height | 6.62" |
| Overall Width | 7 7/25" |
| Regulator Application | General Purpose |
| Seal Material | PTFE |
Shipping Info:
| Ship height (cm) | 16.81 |
| Ship length (cm) | 12.07 |
| Ship width (cm) | 18.49 |
| Country of Origin | US |
