GRAINGER 22504_24_48 Carbon Steel Rectangular Expanded Sheet, 0.11 Inch Overall Thick24 Inch X 4 Feet Size
Item: CP9GVTModel: 22504_24_48Cross Ref: 799FE3
7 In Stock
Ships within 2 days via
10.00% off
€84.77 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Expanded Sheet |
| Brinell Hardness | 140 |
| Diamond Pattern | Flattened |
| Diamond Size | 1.33" x 3.2" |
| Fabrication | Hot Rolled |
| Finish | Mill |
| Grade | Grade A36 |
| Includes Material Certificate | No |
| Length | 4 ft. |
| Long Way Diamond Size | 3 1/5" |
| Long Way Of Opening | 2.563" |
| Machinability | 72% |
| Material | Carbon Steel |
| Material Grade | A36 |
| Mechanical Finish | Mill |
| Open Area | 63% |
| Opening Size | 2.563" x 1" |
| Overall Length | 4 ft. |
| Overall Thickness | 0.11" |
| Overall Width | 24" |
| Rockwell Hardness | Rockwell B84 |
| Shape | Rectangular |
| Short Way Diamond Size | 1.33" |
| Short Way Of Opening | 1" |
| Standards | Astm A36 |
| Strand Thickness | 0.11" |
| Strand Width | 0.158" |
| Tensile Strength | 58000 psi |
| Tolerance Rating | Standard |
| Trade Size | 1 1/2"-#9 |
| Weight Per Area | 9.12 lbs.-sq. ft. |
| Width | 24" |
| Yield Strength | 36000 psi |
Shipping Info:
| Ship weight (kg) | 4.33 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Model | Diamond Pattern | Opening Size | Strand Thickness | Strand Width | Trade Size | Short Way Diamond Size | Open Area | Shape | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 22486_12_48 | Flattened | 0.312" x 1" | 0.039" | 0.097" | 1/2"-#18 | 1/2" | 60% | Rectangular | €43.59 | |
| 22486_36_48 | Flattened | 0.312" x 1" | 0.039" | 0.097" | 1/2"-#18 | 1/2" | 60% | Rectangular | €126.76 | |
| 22486_24_36 | Flattened | 0.312" x 1" | 0.039" | 0.097" | 1/2"-#18 | 1/2" | 60% | Rectangular | €64.88 | |
| 22486_12_36 | Flattened | 0.312" x 1" | 0.039" | 0.097" | 1/2"-#18 | 1/2" | 60% | Rectangular | €47.23 | |
| 22486_12_24 | Flattened | 0.312" x 1" | 0.039" | 0.097" | 1/2"-#18 | 1/2" | 60% | Rectangular | €23.63 | |
| 22485_12_24 | Flattened | 0.118" x 0.715" | 1/25" | 2/25" | 1/4"-#18 | 1/4" | 35% | Rectangular | €95.83 | |
| 22485_12_36 | Flattened | 0.118" x 0.715" | 1/25" | 2/25" | 1/4"-#18 | 1/4" | 35% | Rectangular | €64.15 |
