GOULDS WATER TECHNOLOGY WS2012D4 Submersible Sewage Pump 2hp 230v 19 Feet
Get it by Tuesday, Aug 25
5.00% off
€7,618.34 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Submersible Sewage Pump |
| Amps | 16.3A |
| Base Material | Cast Iron |
| Bearing Type | Ball |
| Body Dia. | 15 3/4" |
| Body Material | Cast Iron |
| Cord Length | 20 ft. |
| Dia. | 15 3/4" |
| Discharge Npt | 4" |
| Discharge Size | 4" |
| Discharge Size | 4"-NPT |
| Discharge Type | Flanged |
| Duty Cycle | Continuous |
| Flow Rate @ 15 Ft. Of Head | 375 GPM |
| Flow Rate @ 20 Ft Of Head | 300 GPM |
| Flow Rate @ 20 Ft. | 300 GPM |
| Flow Rate @ 25 Ft. | 200 GPM |
| Flow Rate @ 30 Ft. | 100 GPM |
| Height | 28 1/4" |
| Hp | 2 hp |
| Impeller Material | Cast Iron |
| Max. Flow Rate @ 15 Ft. | 375 GPM |
| Max. Head | 35 ft. |
| Max. Media Temp. | 104°F |
| Max. Solid Dia. | 3" |
| Motor Type | Capacitor Start |
| Off Point | N/A" |
| Outlet | 4" Flanged |
| Outlet Size | 4" |
| Overall Height | 28 1/4" |
| Phase | 1 |
| Pump Type | Manual Pump |
| Seal Material | Silicon Carbide |
| Series | WS D4 3888 Series |
| Shaft Material | Stainless Steel |
| Shaft Seal Material-pumps | Silicone Carbide |
| Speed | 1750 RPM |
| Switch Actuation | No Switch Included |
| Switch Electrical Connection | No Switch Included |
| Switch Type | None |
| Thermal Protection | Yes |
| Top Material | Cast Iron |
| Voltage | 230V AC |
Shipping Info:
| Ship weight (kg) | 85.5 |
| Ship height (cm) | 69.85 |
| Ship length (cm) | 34.29 |
| Ship width (cm) | 46.99 |
| HS code | 8413702004 |
| Country of Origin | US |
Product Variants
| Model | Hp | Voltage | Phase | Amps | Max. Media Temp. | Flow Rate @ 20 Ft. | Max. Head | Motor Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| WS5034D4 | 5 hp | 460V AC | 3 | 8.3A | 104°F | 525 GPM | 52 ft. | Three Phase | €8,947.10 | |
| WS5032D4 | 5 hp | 230V AC | 3 | 16.6A | 104°F | 525 GPM | 52 ft. | Three Phase | €8,655.46 | |
| WS5012D4 | 5 hp | 230V AC | 1 | 26.5A | 104°F | 525 GPM | 52 ft. | Capacitor Start | €9,997.62 | |
| WS7534D4 | 7 1/2 hp | 460V AC | 3 | 11.5A | 104°F | 620 GPM | 60 ft. | Three Phase | €11,029.35 | |
| WS3034D4 | 3 hp | 460V AC | 3 | 7.2A | 104°F | 440 GPM | 46 ft. | Three Phase | €8,345.76 | |
| WS3012D4 | 3 hp | 230V AC | 1 | 21.5A | 104°F | 440 GPM | 46 ft. | Permanent Split Capacitor | €9,712.75 | |
| WS3032D4 | 3 hp | 230V AC | 3 | 14.4A | 104°F | 440 GPM | 46 ft. | Three Phase | €8,345.76 |
