EATON XTCR150G11B IEC Magnetic Contactor, Reversing, 3 Poles, 150 A, 240 VAC Coil, G Frame Size
Get it by Monday, Aug 24
€ 34,99 Flat Shipping + VAT € 34,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
5.00% off
€5,304.43 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | IEC Magnetic Contactor |
| Action Type | Reversing |
| Auxiliary Contacts Included | 1NO/1NC |
| Coil Voltage | 190/240V AC |
| Contactor Style | IEC |
| Depth | 6.85" , 7 6/25" |
| Embedded Surge Suppressor | Yes |
| Enclosure Nema Rating | No Enclosure |
| Frame Size | G |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 150A |
| Full Load Amps-resistive | 190A |
| Height | 12 4/5" , 7.09" |
| Hp @ 1 Ph-240v | 30 hp |
| Hp @ 1 Phase-120v | 15 hp |
| Hp @ 1 Phase-240v | 30 hp |
| Hp @ 3 Ph-480v | 100 hp |
| Hp @ 3 Phase-208v | 40 hp |
| Hp @ 3 Phase-240v | 60 hp |
| Hp @ 3 Phase-480v | 100 hp |
| Hp @ 3 Phase-575v | 100 hp |
| Hp @ 3 Phase-600v | 100 hp |
| Included Auxiliary Contacts | Yes |
| Integrated Surge Suppression | Yes |
| Ip Rating | IP20 |
| Main Power Pole Contact Form | 3NO |
| Max. Operating Temp. | 122°F |
| Min. Operating Temp. | -13°F |
| Mounting Hole Dia. | 0.27" |
| Mounting Hole Distance | 11.77" |
| Mounting Hole Distance Width | 6.97" |
| Mounting Style | DIN Rail, Panel |
| Nema Enclosure Material | Not Applicable |
| No. Of Auxillary Contacts | 2 |
| No. Of Poles | 3 |
| Nominal Coil Voltage @ 60hz | 240V AC |
| Overall Depth | 7.24" |
| Overall Height | 12 4/5" |
| Overall Width | 7.72" |
| Phase | 3 |
| Reversible | Yes |
| Reversing Capability | Reversing |
| Series | Xt Series Series |
| Terminal Connection Type | Screw Terminal |
| Width | 7 18/25" , 7.09" |
| Wire Termination Type | Screw |
Shipping Info:
| Ship weight (kg) | 6.8 |
| Ship height (cm) | 32.51 |
| Ship length (cm) | 18.39 |
| Ship width (cm) | 19.61 |
| Country of Origin | US |
Product Variants
| Model | No. Of Poles | Height | Coil Voltage | Frame Size | Frequency | Amps | Max. Hp | Continuous Amps | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| XTCE007B01A | 3 | 2" | 110-120V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €250.30 | |
| XTCE007B01C | 3 | 3 1/2" | 415-480V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €239.42 | |
| XTCE007B01E | 3 | 3" | 208V AC | B | 60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €239.42 | |
| XTCE007B01B | 3 | 3.07" | 220-240V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €250.30 | |
| XTCE007B01T | 3 | 1 1/2" | 24V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €250.30 | |
| XTCE007B01TD | 3 | 3" | 24V DC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €334.78 | |
| XTCE007B10A | 3 | 2.67" | 110-120V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €238.92 |
