EATON XTCF045C10D C-Frame IEC Contactor, Non-Reversing, 550 VAC at 50 Hz, 600 VAC at 60 Hz V Coil, 45 A
Get it by Monday, Aug 17
€499.47 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Contactor |
| Amps | 45A |
| Coil Voltage | 550/550-600V AC |
| Contact Configuration | 1 NO |
| Continuous Amps | 1000A |
| Frame Size | 45 mm |
| Frequency | 50-60 Hz , 50/60 Hz |
| Height | 2 3/4" |
| Length | 4 1/2" |
| Max. Hp | 7 1/2, 10, 15, 20 hp (3 Phase @ 200, 230, 460, 575V) |
| Mfr. Series | XT IEC Series |
| No. Of Poles | 4 |
| Notes | Screw Terminals (6-65A), 5 mm (80-150A), No Lugs (185-2000A) |
| Operation | Non-Reversing |
| Product Name | Eaton XT IEC contactor |
| Terminals | Screw Terminal |
| Type | Full Voltage Non-reversing Contactor |
| Width | 4" |
Shipping Info:
| Ship weight (kg) | 0.53 |
| Ship height (cm) | 6.99 |
| Ship length (cm) | 11.43 |
| Ship width (cm) | 10.16 |
| Country of Origin | US |
Product Variants
| Model | Amps | Height | Coil Voltage | No. Of Poles | Continuous Amps | Max. Hp | Frequency | Mfr. Series | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| XTCE018C01AD | 18A | 3.898" | 120V DC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | - | XT IEC Series | €394.34 | |
| XTCE018C01F | 18A | 3.898" | 230V AC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 50 Hz | XT IEC Series | €371.97 | |
| XTCE018C01D | 18A | 3.898" | 550/550-600V AC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 50/60 Hz | XT IEC Series | €322.38 | |
| XTCE018C01G | 18A | 3.898" | 190-220V AC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 50/60 Hz | XT IEC Series | €322.38 | |
| XTCE018C01N | 18A | 3.898" | 400V AC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 50 Hz | XT IEC Series | €322.38 | |
| XTCE018C01L | 18A | 3.898" | 380-440/440-3800V AC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 50/60 Hz | XT IEC Series | €322.38 | |
| XTCE018C01H | 18A | 3.898" | 240-277V AC | 3 | 18A | 2, 2, 3/ 5, 5, 10, 15 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 50/60 Hz | XT IEC Series | €322.38 |
