EATON XTCEXSCC11 Auxiliary Contact, 10 A Max Current AC, Side Mount

Item: BH8YNWModel: XTCEXSCC11Cross Ref: 4TZH9

7 In Stock

Ships within 2 days via

~~€140.48~~

5.00% off

€133.46 /unit

Add To Cart

Request a Quote

Payment

Product Specifications:

Item	Auxiliary Contact
Auxiliary Contact Form	1NO, 1NC
Compatible With Series	Xt Contactors
Contact Configuration	1 NC, 1 NO
Conventional Thermal Amps	10A
Frame Size	C
Height	4.21"
Length	3.31"
Max. Amps (ac)	10A
Max. Voltage	500V AC
Mounting Location	Side
Mounting Type	Side
No. Of Poles	2
Note	Screw Terminals (6-65A), 5 mm (80-150A), No Lugs (185-2000A). Can Be Mounted To The Left Side Of Contactor Only. Cannot Be Used In Combination With Front (Top) Mount Auxiliary Contacts Or Mechanical Interlocks.!
Product Name	Eaton motor control auxiliary contact
Quantity	1
Terminal Connection Type	Screw Clamp Terminals
Terminals	Screw
Type	Contactor Accessory-Auxiliary Contact
Width	1.02"

Shipping Info:

Ship weight (kg)	0.05
Ship height (cm)	10.69
Ship length (cm)	8.41
Ship width (cm)	2.59
Country of Origin	US

Product Variants

Model	Height	Mounting Location	Amps	Contact Configuration	Note	Mounting Type	No. Of Poles	Terminals	Price
NHI11-PKZ2	1 1/2"	-	-	-	-	-	-	-	€141.13
NHI-E-10-PKZ0	1"	-	-	-	-	-	-	-	€61.34
XTCEXFACC22	1 1/2"	-	-	2 NO, 2 NC	Interlocked Opposing Contacts, To IEC/EN 60947-5-1 Annex L (Positively Driven), Within The Auxiliary Contact Modules (Not NOE And NCL Contacts) And Between The Auxiliary Contacts And Built-In Contacts Of The XTRE Control Relays.	Front	4	Spring Cage	€95.89
XTCEXFACC11	1 1/2"	-	-	1 NC, 1 NO	Interlocked Opposing Contacts, To IEC/EN 60947-5-1 Annex L (Positively Driven), Within The Auxiliary Contact Modules (Not NOE And NCL Contacts) And Between The Auxiliary Contacts And Built-In Contacts Of The XTRE Control Relays.	Front	2	Spring Cage	€79.70
XTCEXFAC20	1 1/2"	-	-	2 NO	Interlocked Opposing Contacts, To IEC/EN 60947-5-1 Annex L (Positively Driven), Within The Auxiliary Contact Modules (Not NOE And NCL Contacts) And Between The Auxiliary Contacts And Built-In Contacts Of The XTRE Control Relays.	Front	2	Screw	€49.36
XTCEXFAC31	1 1/2"	-	-	3 NO-1 NC	Interlocked Opposing Contacts, To IEC/EN 60947-5-1 Annex L (Positively Driven), Within The Auxiliary Contact Modules (Not NOE And NCL Contacts) And Between The Auxiliary Contacts And Built-In Contacts Of The XTRE Control Relays.	Front	4	Screw	€93.09
XTCEXFAC04	1.3"	-	-	4 NC	Interlocked Opposing Contacts, To IEC/EN 60947-5-1 Annex L (Positively Driven), Within The Auxiliary Contact Modules (Not NOE And NCL Contacts) And Between The Auxiliary Contacts And Built-In Contacts Of The XTRE Control Relays.	Front	4	Screw	€125.53
