EATON XTCE150G00C IEC Magnetic Contactor, 150A Inductive Full Load, 190A Resistive Full Load
Item: CJ2NVEModel: XTCE150G00CCross Ref: 21EP09
7 In Stock
Ships within 2 days via
5.00% off
€1,761.03 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | IEC Magnetic Contactor |
| Amps | 150A |
| Auxiliary Contacts Included | None |
| Coil Voltage | 480/500V AC |
| Connection | Screw Connection |
| Contactor Style | IEC |
| Depth | 5.59" , 6.73" |
| Electrical Operating Durability | 300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie) |
| Embedded Surge Suppressor | Yes |
| Enclosure Nema Rating | No Enclosure |
| Frame | R |
| Frame Size | G |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 150A |
| Full Load Amps-resistive | 190A |
| Height | 4.37" , 6.89" |
| Hp @ 1 Ph-240v | 30 hp |
| Hp @ 1 Phase-120v | 10 hp |
| Hp @ 1 Phase-240v | 30 hp |
| Hp @ 3 Ph-480v | 125 hp |
| Hp @ 3 Phase-208v | 40 hp |
| Hp @ 3 Phase-240v | 60 hp |
| Hp @ 3 Phase-480v | 125 hp |
| Hp @ 3 Phase-575v | 125 hp |
| Hp @ 3 Phase-600v | 125 hp |
| Included Auxiliary Contacts | No |
| Integrated Surge Suppression | Yes |
| Ip Rating | IP20 |
| Main Power Pole Contact Form | 3NO |
| Max. Operating Temp. | 122°F |
| Max. Voltage | 690V AC |
| Mechanical Operating Durability | 10000000 |
| Min. Operating Temp. | -13°F |
| Mounting Hole Dia. | 6/25" |
| Mounting Hole Distance | 6.14" |
| Mounting Hole Distance Width | 2.79" |
| Mounting Style | DIN Rail, Panel |
| No. Of Auxillary Contacts | 0 |
| No. Of Poles | 3 |
| Nominal Coil Voltage @ 60hz | 480V AC |
| Overall Depth | 6.73" |
| Overall Height | 6.89" |
| Overall Width | 3.58" |
| Product Height | 6.89" |
| Product Width | 3.583" |
| Reversible | No |
| Reversing Capability | Non Reversing |
| Series | Xt Series Series |
| Terminal Connection Type | Screw Terminal |
| Width | 3.58" , 4.37" |
| Wire Termination Type | Screw |
Shipping Info:
| Ship weight (kg) | 2.8 |
| Ship height (cm) | 17.5 |
| Ship length (cm) | 17.09 |
| Ship width (cm) | 9.09 |
| Country of Origin | DE |
Product Variants
| Model | No. Of Poles | Height | Coil Voltage | Frame Size | Frequency | Amps | Max. Hp | Continuous Amps | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| XTCE007B01A | 3 | 2" | 110-120V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €250.30 | |
| XTCE007B01C | 3 | 3 1/2" | 415-480V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €239.42 | |
| XTCE007B01E | 3 | 3" | 208V AC | B | 60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €239.42 | |
| XTCE007B01B | 3 | 3.07" | 220-240V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €250.30 | |
| XTCE007B01T | 3 | 1 1/2" | 24V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €250.30 | |
| XTCE007B01TD | 3 | 3" | 24V DC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €334.78 | |
| XTCE007B10A | 3 | 2.67" | 110-120V AC | B | 50/60 Hz | 7A | 1/4, 3/4, 1/ 1 1/2, 2, 3, 5 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V) | 7A | €238.92 |
