EATON HT8AEGA Non-Illuminated Pushbutton, 40 mm, 1NO Contact, Green
Item: BH3MHXModel: HT8AEGACross Ref: 13Z577
7 In Stock
Ships within 2 days via
10.00% off
€197.49 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pushbutton |
| Ac Contact Rating | 10A @ 600V |
| Action | Momentary |
| Actuator Color | Green |
| Actuator Material | Plastic |
| Actuator Type | Mushroom |
| Bezel | Chrome |
| Bezel Material | Chrome |
| Bus Material | Aluminum |
| Contact Configuration | 1 NO |
| Contact Form | 1NO |
| Dc Contact Rating | 5A @ 250V |
| Display Qty | 1 |
| Features | Allen Bradley Pushbutton Panel Compatible |
| Head Material | Metal |
| Head/lens Color | Green |
| Height | 5" |
| Illumination | Non-Illuminated |
| Ip Rating | IP66 |
| Length | 3" |
| Manufacturer Warranty Length | 1 yr. |
| Mechanical Operating Durability | 1 x 10^7 |
| Mushroom Head Diameter | 40 mm |
| Nema Enclosure Rating | NEMA 1, NEMA 12, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X |
| Number Of Indicator Lights | 0 |
| Number Of Operators | 1 |
| Operating Mode | Momentary |
| Operating Temperature - Maximum | 140°F |
| Operating Temperature - Minimum | 10°F |
| Operator Illumination | Non Illuminated |
| Operator Material | Metal |
| Operator Voltage Rating - Maximum | 28V |
| Overall Depth | 3" |
| Overall Height | 5" |
| Panel Mounting Hole Diameter | 30 mm |
| Product Type | Push Button Operators |
| Push Button Style | Mushroom Head |
| Resistance Properties | Oil And Grease Resistant, Watertight |
| Series | Ht800 Series |
| Size | 40 mm |
| Standards | Ce, Csa, Ul Listed |
| Terminal Connection | Screw Clamp |
| Type | Pushbutton |
| Warranty | 1 yr. |
| Width | 2" |
Shipping Info:
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 12.7 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 5.08 |
| HS code | 8536.50 |
| Country of Origin | DO |
Product Variants
| Product | Model | Contact Form | Size | Type | Contact Configuration | Head Material | Bezel | Ip Rating | Bezel Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HT8DBRAB | 1NO/1NC | 40 mm | 30.5 mm, Watertight/Oiltight-HT800 | - | Metal | Chrome | IP66 | Chrome | €289.61 | |
 |
HT8CBRAB | 1NO/1NC | 40 mm | 30.5 mm, Watertight/Oiltight-HT800 | - | Metal | Chrome | IP66 | Chrome | €289.61 | |
 |
HT8DBGA | 1NO | 40 mm | Push-Pull | 1 NO | Metal | Chrome | IP66 | Chrome | €206.45 | |
 |
HT8DBHB | - | 40 mm | Push-Pull | 1 NC | - | Chrome | - | - | €267.83 | |
|
HT8CBGA | 1NO | 40 mm | Push-Pull | 1 NO | Metal | Chrome | IP66 | Chrome | €205.98 | |
|
HT8CBGAB | 1NO/1NC | 40 mm | Push-Pull | 1 NC, 1 NO | Metal | Chrome | IP66 | Chrome | €247.01 | |
|
HT8CBGB | 1NC | 40 mm | Push-Pull | 1 NC | Metal | Chrome | IP66 | Chrome | €217.56 |
