EATON HFD3090 Molded Case Circuit Breaker, F-Frame, Type Hfd, 3-Pole, 90 A, 600 Vac, 250 Vdc, 50/60 Hz
Item: AG8PEJModel: HFD3090Cross Ref: 46MX77
7 In Stock
Ships within 2 days via
10.00% off
€1,534.28 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Circuit Breaker |
| Ac Voltage Rating | 600V AC |
| Amps | 90A |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Free Standing |
| Circuit Breaker Type | Standard |
| Dc Voltage Rating | 250V AC |
| Depth | 3.38" |
| For Use With | Allen Bradley Mcc, Eaton Mcc Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse |
| Frame Size | 225A/F |
| Height | 3.38" |
| High Amp Trip Setting | 225A |
| Instantaneous Trip | Fixed |
| Length | 3.38" |
| Low Amp Trip Setting | 15A |
| Max. Air Rating | 100 kA At 240V AC |
| Max. Operating Temp. | 158°F |
| Max. Wire Size | 1/0 AWG |
| Min. Operating Temp. | -4°F |
| Min. Wire Size | 14 AWG |
| Number Of Poles | 3 |
| Phase | Three |
| Phase Connection | ABC |
| Series | HFD Series |
| Terminal Connection | Load Side Lug |
| Trip Type | Thermal Magnetic |
| Voltage Type | AC |
| Warranty | Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First. |
| Width | 4.13" |
Shipping Info:
| Ship weight (kg) | 1.94 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 8.59 |
| Ship width (cm) | 10.49 |
| Country of Origin | US |
Product Variants
| Product | Model | Amps | Circuit Breaker Type | Frame Size | Number Of Poles | Ac Voltage Rating | Phase | Phase Connection | Min. Wire Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HFD2225 | - | - | - | - | - | - | - | - | €2,118.83 | |
|
HFD3015 | 15A | Standard | 225A/F | 3 | 600V AC | Three | ABC | 14 AWG | €1,376.74 | |
|
HFD3020 | - | - | - | - | - | - | - | - | €1,376.74 | |
|
HFD3025 | 25A | Standard | 225A/F | 3 | 600V AC | Three | ABC | 14 AWG | €2,483.90 | |
|
HFD3030 | 30A | Standard | 225A/F | 3 | 600V AC | Three | ABC | 14 AWG | €2,773.85 | |
 |
HFD3035 | - | - | - | - | - | - | - | - | €1,704.76 | |
|
HFD3040 | 40A | Standard | 225A/F | 3 | 600V AC | Three | ABC | 14 AWG | €1,376.74 |
