EATON ECSJ422SP Current Switch, 40-120 ms Response, Isolated Solid State Relay/NO Output, 30 VDC
Get it by Tuesday, Aug 25
€371.35 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Switch |
| Connection | Screw Terminal |
| Contact Configuration | SSR |
| Contact Rating | 0.15A at 30V DC |
| Enclosure Material | Plastic |
| Led Indicator | LED Indicator |
| Length | 3.53" |
| Max. Ac Amps | 200A |
| Operating Temp. | -58°F to +122°F |
| Product Height | 2 1/4" |
| Product Name | Eaton ECS Series CurrentWatch AC Current Switch |
| Product Width | 1.19" |
| Switch Type | Current Switch |
Shipping Info:
| Ship height (cm) | 5.72 |
| Ship length (cm) | 8.97 |
| Ship width (cm) | 3.02 |
| Country of Origin | US |
Product Variants
| Product | Model | Product Width | Product Height | Amps | Contact Configuration | Contact Rating | Max. Ac Amps | Operating Temp. | Overall Depth | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
ECS701SC | 0.93" | 3 1/2" | - | Isolated Solid State Relay | 0.3A at 135V AC/DC | 150A, 0.3A | - | - | €466.85 | |
 |
ECS700SC | 0.93" | 2.18" | - | SSR | 0.3A at 135V AC/DC | 150A | - | - | €200.07 | |
|
ECS702SC | 0.93" | 3 1/2" | - | Isolated Solid State Relay | 0.3A at 135V AC/DC | 150A, 0.3A | - | - | €447.37 | |
 |
ECS710SP | 1.19" | 2 1/4" | 2.8-150A | SSR | 0.3A at 135V AC/DC | 150A | - | - | €415.74 | |
 |
ECS712SP | 1.19" | 2 1/4" | - | SSR | 0.3A at 135V AC/DC | 150A | - | - | €440.85 | |
 |
ECS711SP | 1.19" | 3.53" | - | Isolated Solid State Relay | 0.3A at 135V AC/DC | 150A, 0.3A | - | - | €603.80 | |
 |
ECSJ402SP | 1.19" | 3.53" | - | Isolated Solid State Relay | 1A at 240V AC | 200A, 1A | -58°F to +122°F | - | €330.36 |
